P600A-P600M
GENERAL PURPOSE RECTIFIERS
50V-1000V
6.0A
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Rectified Output Current
(Note 1)
@T
A
= 60°C
Non-Repetitive Peak Forward Surge Current
8.3ms Single half sine-wave superimposed on
rated load (JEDEC Method)
Forward Voltage
Peak Reverse Current
At Rated DC Blocking Voltage
@I
F
= 6.0A
@T
A
= 25°C
@T
A
= 100°C
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
O
P600A
P600B
P600D
P600G
P600J
P600K
P600M
Unit
50
35
100
70
200
140
400
280
6.0
600
420
800
560
1000
700
V
V
A
I
FSM
V
FM
I
RM
C
j
R
JA
T
j
T
STG
400
1.0
5.0
1.0
150
20
-50 to +150
-50 to +150
A
V
µA
mA
pF
K/W
°C
°C
Typical Junction Capacitance (Note 2)
Typical Thermal Resistance Junction to Ambient
(Note 1)
Operating Temperature Range
Storage Temperature Range
*Glass passivated forms are available upon request
Note: 1. Leads maintained at ambient temperature at a distance of 9.5mm from the case
2. Measured at 1.0 MHz and applied reverse voltage of 4.0V D.C.
E-mail: sales@taychipst.com
1 of 2
Web Site: www.taychipst.com
P600A THRU P600M
GENNERAL PURPOSE RECTIFIERS
8
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
100
50V-1000V 6.0A
7
I
O
, AVERAGE RECTIFIED CURRENT (A)
6
5
4
3
2
1
0
0
25
50
75
100
125
150 175
200
10
1.0
T
j
= 25ºC
Pulse Width = 300
µ
s
2% Duty Cycle
0.1
0
0.2
0.6
1.0
1.4
1.8
T
A
, AMBIENT TEMPERATURE (ºC)
Fig. 1 Forward Current Derating Curve
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2, Typical Forward Characteristics
500
I
FSM
, PEAK FORWARD SURGE CURRENT (A)
1000
T
j
= 25°C
f = 1MHz
300
C
j
, CAPACITANCE (pF)
8.3ms Single Half Sine-Wave
JEDEC Method
400
100
200
100
0
1
10
NUMBER OF CYCLES AT 60Hz
Fig. 3 Maximum Non-Repetitive Peak Forward Surge Current
100
10
1
10
V
R
, REVERSE VOLTAGE (V)
Fig. 4 Typical Junction Capacitance
100
E-mail: sales@taychipst.com
2 of 2
Web Site: www.taychipst.com
