T-1 (3mm) RESISTOR LED LAMPS
L-934ID-12V
L-934GD-12V
L-934YD-12V
L-934SGD-12V
L-934SRD-12V
HIGH EFFICIENCY RED
GREEN
YELLOW
SUPER BRIGHT GREEN
SUPER BRIGHT RED
Features
!
12
Description
The High Efficiency Red source color devices are made with
Gallium Arsenide Phosphide on Gallium Phosphide Orange
Light Emitting Diode.
The Green and Super Bright Green source color devices
are made with Gallium Phosphide Green Light Emitting
Diode.
The Yellow source color devices are made with Gallium
Arsenide Phosphide on Gallium Phosphide Yellow Light
Emitting Diode.
The Super Bright Red source color devices are made with
Gallium Aluminum Arsenide Red Light Emitting Diode.
CURRENT LIMITING RESISTOR.
VOLT SERIES IN T-1 PACKAGES.
EXTERNAL CURRENT LIMITER REQUIRED WITH
EFFECTIVE - SAVE SPACE AND RESISTOR
VIEWING ANGLE.
IN ALL COLORS.
!
INTEGRAL
!
NO
12 VOLT SUPPLY.
!
COST
COST.
!
WIDE
!
AVAILABLE
!
12V
INTERNAL RESISTOR.
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
SPEC NO: KDA0193
APPROVED: J.LU
REV NO: V.1
CHECKED:
DATE: OCT/04/2001
DRAWN: J.X.FU
PAGE: 1 OF 5
Selection Guide
Par t No .
L-934ID-12V
L-934GD-12V
L-934YD-12V
L-934SGD-12V
L-934SRD-12V
Dic e
HIGH EFFICIENCY RED(GaAsP/GaP)
GREEN (GaP)
YELLOW (GaAsP/GaP)
SUPER BRIGHT GREEN(GaP)
SUPER BRIGHT RED(GaAlAs)
L en s Ty p e
RED DIFFUSED
GREEN DIFFUSED
YELLOW DIFFUSED
GREEN DIFFUSED
RED DIFFUSED
8
8
8
8
40
Iv (m c d )
VF=12V
Min.
Typ.
20
20
15
20
100
V i ew i n g
An g l e
2θ1/2
60 °
60 °
60 °
60 °
60 °
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value..
°
Electrical / Optical Characteristics at T
)
=25°C
Sy m b o l
Par am et er
D ev i c e
High Efficiency Red
Green
Yellow
Super Bright Red
Super Bright Green
High Efficiency Red
Green
Yellow
Super Bright Red
Super Bright Green
High Efficiency Red
Green
Yellow
Super Bright Red
Super Bright Green
High Efficiency Red
Green
Yellow
Super Bright Red
Super Bright Green
All
Ty p .
627
565
590
660
565
625
568
588
640
568
45
30
35
20
30
8.5
8.5
8.5
8.5
8.5
10
Un it s
Tes t Co n d it io n s
λ
peak
Peak Wavelength
nm
VF=12V
λD
Wavelength current
nm
VF=12V
∆λ
1/2
Spectral Line Halfwidth
nm
VF=12V
I
F
Forward Current
mA
VF=12V
I
R
Reverse Current
uA
V R = 5V
SPEC NO: KDA0193
APPROVED: J.LU
REV NO: V.1
CHECKED:
DATE: OCT/04/2001
DRAWN: J.X.FU
PAGE: 2 OF 5
Absolute Maximum Ratings at T
)
=25°C
°
Par am et er
Power dissipation
Forward voltage (max)
Reverse Voltage
Operating Temperature
Storage Temperature
Lead Solder Temperature [1]
Note:
1. 4mm below package base.
Hig h
E f f i c i en c y
R ed
120
14
5
Gr een
120
14
5
Yello w
120
14
5
S u p er
B r i g h t R ed
12 0
14
5
S u p er
B r ig h t Gr een
12 0
14
5
Un it s
mW
V
V
-40
°
C To +70
°C
-40
°
C To +85
°C
260
°
C For 5 Seconds
High Efficiency Red L-934ID-12V
SPEC NO: KDA0193
APPROVED: J.LU
REV NO: V.1
CHECKED:
DATE: OCT/04/2001
DRAWN: J.X.FU
PAGE: 3 OF 5
