BZG47.. , BZG47..A
Vishay Telefunken
Silicon Z–Diodes
Features
D
D
D
D
D
D
Passivated junction
High reliability
Voltage range 3.3 V to 100 V
Fits onto 5 mm SMD footpads
Wave and reflow solderable
V
Znom
±10%
and
±5%
tolerance
15 811
Applications
Voltage stabilization
Absolute Maximum Ratings
T
j
= 25
_
C
Parameter
Power dissipation
Non repetitive peak surge
power dissipation
Junction temperature
Storage temperature range
Test Conditions
R
thJA
<100K/W, T
amb
=25
°
C
t
p
=100
m
s sq.pulse,
T
j
=25
°
C prior to surge
Type
Symbol
P
V
P
ZSM
T
j
T
stg
Value
1.25
50
150
–65...+150
Unit
W
W
°
C
°
C
Maximum Thermal Resistance
T
j
= 25
_
C
Parameter
Test Conditions
Junction lead
Junction ambient mounted on epoxy–glass hard tissue, Fig. 1a
mounted on epoxy–glass hard tissue, Fig. 1b
mounted on Al–oxid–ceramic (Al
2
O
3
), Fig. 1b
Symbol
R
thJL
R
thJA
R
thJA
R
thJA
Value
35
150
125
100
Unit
K/W
K/W
K/W
K/W
Electrical Characteristics
T
j
= 25
_
C
Parameter
Forward voltage
Test Conditions
I
F
=0.2A
Type
Symbol
V
F
Min
Typ
Max
1.2
Unit
V
Document Number 85623
Rev. 5, 06-Aug-99
www.vishay.de
•
FaxBack +1-408-970-5600
1 (4)
BZG47.. , BZG47..A
