DATA SHEET
DME, DMF, DMJ Series: Silicon Beam-Lead Schottky Mixer
Diodes – Singles, Pairs & Quads, Bondable & Packaged Chips
Applications
Microwave Integrated Circuits
Mixers
Detectors
Features
Low 1/f noise
Low intermodulation distortion
Epoxy and hermetically sealed packages
Statistical Process Control wafer fabrication
Packages rated MSL1, 260 C per JEDEC J-STD-020)
Skyworks offers lead (Pb)-free, RoHS (Restriction of
Hazardous Substances) compliant packaging.
Beam-lead Schottky barrier diodes are categorized by universal
mixer applications in four frequency ranges: S, C, X, Ku, K, and Ka
bands as noted in Table 1. They may also be used as modulators
and high-speed switches.
Beam-lead diodes are suited for balanced mixers, due to their low
parasitics and uniformity.
Description
Skyworks beam-lead silicon Schottky barrier mixer diodes are
designed for applications through 40 GHz. The beam-lead design
reduces the problem of bonding to the very small area
characteristic of low capacitance junctions.
Beam-lead Schottky barrier mixer diodes are made by the
deposition of a suitable barrier metal on an epitaxial silicon
substrate to form the junction. The process and choice of
materials result in low series resistance with a narrow spread of
capacitance values for close impedance control.
A variety of forward voltages are available ranging from low values
for low, or starved, local oscillator drive levels to high values for high
drive, low distortion mixer applications. Beam-lead diodes are
available in a wide range of packages. Capacitance ranges and
series resistances are comparable with the packaged devices that
are available up to, and including, the Ka-band. Unpackaged diodes
are well suited for use in Microwave Integrated Circuits (MICs). The
packaged devices are designed to be inserted as hybrid elements in
strip, transmission line applications.
The absolute maximum ratings of the DME, DMF, and DMJ series
of Schottky mixer diodes are provided in Table 2. Electrical and
physical specifications are provided in Tables 3 through 15.
Typical performance characteristics are shown in Figures 1
through 3. Typical mixer circuits are shown in Figure 4.
T
a
ble 1. Frequency Table
Frequency Band
S
C
X
Ku
K
Ka
Frequency
(GHz)
2 to 4
4 to 8
8.2 to 12.4
12.4 to 18.0
18.0 to 26.5
26.5 to 40.0
Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com
200725B • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • October 2, 2009
1
DATA SHEET • DME, DMF, DMJ SERIES SCHOTTKY MIXER DIODES
Table 2. Absolute Maximum Ratings
Parameter
Maximum current
Power dissipation (continuous wave)
Storage temperature
Operating temperature
Note:
Symbol
Imax
Pd
T
STG
T
A
Minimum
Typical
Maximum
100
75
Units
mA
mW/junction
C
C
–65
–65
+175
+175
Exposure to maximum rating conditions for extended periods may reduce device reliability. There is no damage to device with only one parameter set at the limit and all other
parameters set at or below their nominal value. Exceeding any of the limits listed here may result in permanent damage to the device.
CAUTION:
Although these devices are designed to be as robust as possible, Electrostatic Discharge (ESD) can damage them. These
devices must be protected at all times from ESD. Static charges may easily produce potentials of several kilovolts on the
human body or equipment, which can discharge without detection. Industry-standard ESD precautions should be used at all
times.
Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com
2
October 2, 2009 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • 200725B
DATA SHEET • DME, DMF, DMJ SERIES SCHOTTKY MIXER DIODES
Table 3. Electrical Specifications: Beam-Lead Single N-Type Low, Medium, High Drive Schottky Diodes
V
B
@ 10
μA
(V)
Min.
2
3
4
2
3
4
2
3
4
2
3
4
200 to 260
300 to 400
500 to 600
220 to 300
325 to 425
550 to 650
260 to 330
350 to 450
500 to 680
270 to 350
375 to 550
600 to 700
low
medium
high
low
medium
high
low
medium
high
low
medium
high
491-011
491-011
491-011
491-011
491-011
491-011
491-011
491-011
491-011
491-011
491-011
491-011
Part Number
DMF2820-000
DME2127-000
DMJ2823-000
DMF2821-000
DME2957-000
DMJ2777-000
DMF2344-000
DME2333-000
DMJ2824-000
DMF2822-000
DME2458-000
DMJ2825-000
Frequency Band
S, C
S, C
S, C
X
X
X
Ku
Ku
Ku
K, Ka
K, Ka
K, Ka
C
J
@ 0 V, 1 MHz
(pF)
0.30 to 0.50
0.30 to 0.50
0.30 to 0.50
0.15 to 0.30
0.15 to 0.30
0.15 to 0.30
0.05 to 0.15
0.05 to 0.15
0.05 to 0.15
0.1 max
0.1 max
0.1 max
R
S
@ 5 mA
(Ω)
Max.
5
5
5
8
8
8
13
13
13
18
18
18
V
F
@ 1 mA
(mV)
Drive Level
Outline Drawing
Table 4. Epoxy and Hermetic Packaged Beam-Lead Single N-Type Low, Medium, High Drive Schottky Diodes
Part Numbers/Outline Drawings
Epoxy Stripline
250
DMF2820-250
DME2127-250
DMJ2823-250
DMF2821-250
DME2957-250
DMJ2777-250
DMF2344-250
DME2333-250
DMJ2824-250
–
–
–
Epoxy Stripline
230
–
–
–
–
–
–
DMF2344-230
DME2333-230
DMJ2824-230
DMF2822-230
DME2458-230
DMJ2825-230
Hermetic Stripline
220
DMF2820-220
DME2127-220
DMJ2823-220
DMF2821-220
DME2957-220
DMJ2777-220
DMF2344-220
DME2333-220
DMJ2824-220
DMF2822-220
DME2458-220
DMJ2825-220
Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com
200725B • Skyworks Proprietary and Confidential information • Products and Product Information are Subject to Change Without Notice • October 2, 2009
3
DATA SHEET • DME, DMF, DMJ SERIES SCHOTTKY MIXER DIODES
Table 5. Electrical Specifications: Beam-Lead Series Pair, N-Type Low, Medium, High Drive Schottky Diodes
Part Number
DMF2835-000
DME2050-000
DMJ2092-000
DMF2826-000
DME2829-000
DMJ2093-000
DMF2827-000
DME2830-000
DMJ2832-000
DMF2828-000
DME2831-000
DMJ2833-000
Frequency Band
S, C
S, C
S, C
X
X
X
Ku
Ku
Ku
K, Ka
K, Ka
K, Ka
C
J
@ 0 V, 1 MHz
(pF)
0.30 to 0.50
0.30 to 0.50
0.30 to 0.50
0.15 to 0.30
0.15 to 0.30
0.15 to 0.30
0.05 to 0.15
0.05 to 0.15
0.05 to 0.15
0.1 max
0.1 max
0.1 max
R
S
@ 5 mA
(Ω)
Max.
5
5
5
8
8
8
13
13
13
18
18
18
V
B
@ 10
μA
(V)
Min.
2
3
4
2
3
4
2
3
4
2
3
4
V
F
@ 1 mA
(mV)
200 to 260
300 to 400
500 to 600
220 to 300
325 to 425
550 to 650
260 to 330
350 to 450
500 to 680
270 to 350
375 to 550
600 to 700
Drive Level
low
medium
high
low
medium
high
low
medium
high
low
medium
high
Outline Drawing
504-012
504-012
504-012
504-012
504-012
504-012
504-012
504-012
504-012
504-012
504-012
504-012
Table 6. Epoxy and Hermetic Packaged Beam-Lead Series Pair N-Type Low, Medium, High Drive Schottky Diodes
Part Numbers/Outline Drawings
Epoxy Stripline
252
DMF2835-252
DME2050-252
DMJ2092-252
DMF2826-252
DME2829-252
DMJ2093-252
DMF2827-252
DME2830-252
DMJ2832-252
–
–
–
Epoxy Stripline
232
–
–
–
–
–
–
DMF2827-232
DME2830-232
DMJ2832-232
DMF2828-232
DME2831-232
DMJ2833-232
Hermetic Stripline
222
DMF2835-222
DME2050-222
DMJ2092-222
DMF2826-222
DME2829-222
DMJ2093-222
DMF2827-222
DME2830-222
DMJ2832-222
DMF2828-222
DME2831-222
DMJ2833-222
Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com
4
October 2, 2009 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • 200725B
DATA SHEET • DME, DMF, DMJ SERIES SCHOTTKY MIXER DIODES
Table 7. Electrical Specifications: Beam-Lead Common Cathode, N-Type Low, Medium, High Drive Schottky Diodes
Part Number
DMF2182-000
DME2205-000
DMJ2208-000
DMF2183-000
DME2206-000
DMJ2209-000
DMF2184-000
DME2207-000
DMJ2210-000
DMF2834-000
DME2864-000
DMJ2836-000
Frequency Band
S, C
S, C
S, C
X
X
X
Ku
Ku
Ku
K, Ka
K, Ka
K, Ka
C
J
@ 0 V, 1 MHz
(pF)
0.30 to 0.50
0.30 to 0.50
0.30 to 0.50
0.15 to 0.30
0.15 to 0.30
0.15 to 0.30
0.05 to 0.15
0.05 to 0.15
0.05 to 0.15
0.1 max
0.1 max
0.1 max
R
S
@ 5 mA
(Ω)
Max.
5
5
5
8
8
8
13
13
13
18
18
18
V
B
@ 10
μA
(V)
Min.
2
3
4
2
3
4
2
3
4
2
3
4
V
F
@ 1 mA
(mV)
200 to 260
300 to 400
500 to 600
220 to 300
325 to 425
550 to 650
260 to 330
350 to 450
500 to 680
270 to 350
375 to 550
600 to 700
Drive Level
low
medium
high
low
medium
high
low
medium
high
low
medium
high
Outline Drawing
504-013
504-013
504-013
504-013
504-013
504-013
504-013
504-013
504-013
504-013
504-013
504-013
Table 8. Epoxy and Hermetic Packaged Beam-Lead Common Cathode N-Type Low, Medium, High Drive Schottky Diodes
Part Numbers/Outline Drawings
Epoxy Stripline
253
DMF2182-253
DME2205-253
DMJ2208-253
DMF2183-253
DME2206-253
DMJ2209-253
DMF2184-253
DME2207-253
DMJ2210-253
–
–
–
Hermetic Stripline
223
DMF2182-223
DME2205-223
DMJ2208-223
DMF2183-223
DME2206-223
DMJ2209-223
DMF2184-223
DME2207-223
DMJ2210-223
DMF2834-223
DME2864-223
DMJ2836-223
Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com
200725B • Skyworks Proprietary and Confidential information • Products and Product Information are Subject to Change Without Notice • October 2, 2009
5
