VS-FCSP140LTR

www.vishay.com

Vishay Semiconductors

FlipKY

1 A Chip Scale Package Schottky Barrier Rectifier

FEATURES

• Ultra low V

per footprint area

• Low leakage

• Low thermal resistance

• One-fifth footprint of SMA

• Super low profile (0.6 mm)

• Available tested on tape and reel

• Compliant to RoHS Directive 2002/95/EC

APPLICATIONS

FlipKY

• Reverse polarity protection

• Current steering

• Freewheeling

• Flyback

• Oring

DESCRIPTION

PRODUCT SUMMARY

F(AV)

at I

max. at 25 °C

max. at 125 °C

max.

40 V

0.38 V

80 μA

20 mA

150 °C

10 mJ

Vishay’s FlipKY

product family utilizes wafer level

chip scale packaging to deliver Schottky diodes with the

lowest V

to PCB footprint area in industry. The four

bump 1.5 mm x 1.5 mm devices can deliver up to 1 A and

occupy only 2.3 mm

of board space. The anode and

cathode connections are made through solder bump pads

on one side of the silicon enabling designers to strategically

place the diodes on the PCB. This design not only minimizes

board space but also reduces thermal resistance and

inductance, which can improve overall circuit efficiency.

Typical applications include hand-held, portable equipment

such as cell phones, MP3 players, bluetooth, GPS, PDAs,

and portable hard disk drives where space savings and

performance are crucial.

MAJOR RATINGS AND CHARACTERISTICS

SYMBOL

RRM

F(AV)

FSM

1 A

, T

= 125 °C

Rectangular waveform

CHARACTERISTICS

MAX.

250

0.38

- 55 to 150

UNITS

°C

VOLTAGE RATINGS

PARAMETER

Maximum DC reverse voltage

Maximum working peak reverse voltage

SYMBOL

RWM

VS-FCSP140LTR

UNITS

Revision: 04-Jul-11

Document Number: 94495

For technical questions within your region:

DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com

THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT

ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT

www.vishay.com/doc?91000
