SK1020D2 ... SK10100D2
SK1020D2 ... SK10100D2
Surface Mount Schottky Rectifiers – Single Diode
Schottky-Gleichrichter für die Oberflächenmontage – Einzeldiode
Version 2010-09-22
1.2
4.5
±
0.2
10.25
±0.5
4
Type
Typ
Nominal Current
Nennstrom
Repetitive peak reverse voltage
Periodische Spitzensperrspannung
1.3
10 A
20...100 V
TO-263AB
D²PAK
1.6 g
1
2
3
0.8
0.4
5.08
Plastic case
Kunststoffgehäuse
Weight approx.
Gewicht ca.
Plastic material has UL classification 94V-0
Gehäusematerial UL94V-0 klassifiziert
Standard packaging in tubes
Standard Lieferform in Stangen
4
K
1 2 3
Dimensions - Maße [mm]
Maximum ratings and Characteristics
Type
Typ
Repetitive peak reverse voltage
Periodische Spitzensperrspannung
V
RRM
[V]
20
30
40
45
50
60
80
100
Surge peak reverse voltage
Stoßspitzensperrspannung
V
RSM
[V]
20
30
40
45
50
60
80
100
T
C
= 100°C
f > 15 Hz
SK1020D2...
SK1060D2
T
A
= 25°C
Grenz- und Kennwerte
Forward Voltage
Durchlass-Spannung
V
F
[V]
1
)
I
F
= 5 A
I
F
= 10 A
< 0.55
< 0.55
< 0.55
< 0.55
< 0.65
< 0.65
< 0.83
< 0.83
10 A
30 A
2
)
135/150 A
115/125 A
80 A
2
s
-50...+150°C
-50...+175°C
< 0.51
< 0.51
< 0.51
< 0.51
< 0.57
< 0.57
< 0.71
< 0.71
I
FAV
I
FRM
I
FSM
I
FSM
i
2
t
T
j
T
S
SK1020D2
SK1030D2
SK1040D2
SK1045D2
SK1050D2
SK1060D2
SK1080D2
SK10100D2
Max. average forward rectified current, R-load
Dauergrenzstrom in Einwegschaltung mit R-Last
Repetitive peak forward current
Periodischer Spitzenstrom
Peak forward surge current,
50/60 Hz half sine-wave
Stoßstrom für eine 50/60 Hz Sinus-Halbwelle
Rating for fusing – Grenzlastintegral, t < 10 ms
Junction temperature – Sperrschichttemperatur
Storage temperature – Lagerungstemperatur
SK1080D2...
T
A
= 25°C
SK10100D2
T
A
= 25°C
1
2
T
j
= 25°C
Max. temperature of the case T
C
= 100°C – Max. Temperatur des Gehäuses T
C
= 100°C
http://www.diotec.com/
© Diotec Semiconductor AG
1
SK1020D2 ... SK10100D2
Characteristics
Leakage current
Sperrstrom
Leakage current
Sperrstrom
SK1020D2...
SK1045D2
T
j
= 25°C
T
j
= 100°C
V
R
= V
RRM
V
R
= V
RRM
I
R
I
R
R
thC
Kennwerte
< 300 µA
< 45 mA
< 200 µA
< 25 mA
< 1.5 K/W
SK1050D2...
T
j
= 25°C
SK10100D2 T
j
= 100°C
Thermal resistance junction to case
Wärmewiderstand Sperrschicht - Gehäuse
120
[%]
100
10
2
[A]
10
SK1020D2...SK1045D2
SK1050D2, SK1060D2
80
1
60
40
10
-1
20
I
FAV
0
0
T
C
50
100
150
[°C]
I
F
10
-2
SK1080D2, SK10100D2
0
Rated forward current vs. temp. of the case
Zul. Richtstrom in Abh. v. d. Gehäusetemperatur
0.4
0.6
1.0
V
F
[V]
Forward characteristics (typical values)
Durchlasskennlinien (typische Werte)
