HIGH POWER CHIP, ALUMINUM NITRIDE
RESISTORS, TERMINATIONS
50 & 100 OHMS
GENERAL INFORMATION
When mounted on an appropriate heat sink, these chip devices provide
high power dissipation in terminations and as balancing resistors in
Wilkinson power divider networks. Laser trimming provides maximum peak
and average R.F. power capability. Aluminum nitride is used for those
applications where the use and disposal of beryllium oxide is a concern.
SERIES ANC
GENERAL SPECIFICATIONS
Resistive Tolerance:
Solderable Terminals:
Substrate :
Resistive Element:
2%
Electroplated Silver over Nickel
Aluminum Nitride
Thin Film
(FULL FILM)
(NARROW FILM)
Notes:
1. The “L” and “T” dimensions are for the substrate only and do not
include terminal thickness or optional tinning thickness.
2. The CW power rating is based on maximum film temperature of
+150°C and with maximum heatsink temperature of +100°C. Power is
based on infinite and ideal heatsink.
TOP
VIEW
W
A
B
B
50 Ohms
or
100 Ohms
TYPICAL MODEL NO.
ANC
NPC
Prefix
Tinning
(if required)
Size
Terminal type (X, G)
Ohmic Value (
*
)
50
50
TYPICAL MODEL NO.
or
T
250-250 X
X
100
TYPE X
(RESISTOR)
T
L
B
TYPE G
(TERMINATION)
T
50 Ohms
ONLY
L
0.005
[0,13]
MAX
PERFORMANCE SPECIFICATIONS
Model Prefix
ANC 50-50
ANC 50-100
ANC 100-200
ANC 200-200
ANC 250-250-40
ANC 250-250-80
ANC 250-375
ANC 350-225
ANC 375-375
W
in [mm]
0.050 [1,3]
0.050 [1,3]
0.100 [2,5]
0.200 [5,1]
0.250 [6,4]
0.250 [6,4]
0.250 [6,4]
0.350 [8,9]
0.375 [9,5]
L
in
[mm]
in
0.050 [1,3]
0.100 [2,5]
0.200 [5,1]
0.200 [5,1]
0.250 [6,4]
0.250 [6,4]
0.375 [9,5]
0.225 [5,7]
0.375 [9,5]
T
[mm]
in
N/A
N/A
N/A
0.085 [2,2]
0.085 [2,2]
N/A
N/A
0.02 [.508]
0.25 [6,4]
0.010 [.254]
0.010 [.254]
0.040 [1,0]
0.040 [1,0]
0.040 [1,0]
0.040 [1,0]
0.040 [1,0]
0.040 [1,0]
0.040 [1,0]
A
[mm]
B
in
[mm]
0.010 [.254]
0.020 [.508]
0.030 [.762]
0.040 [1,0]
0.050 [1,3]
0.050 [1,3]
0.050 [1,3]
0.050 [1,3]
0.050 [1,3]
Resistor
CAP(pF)
Typical
0.5
1.0
1.0
1.2
1.0
1.6
4.5
1.4
4.5
Termination
VSWR
Typical
1.25
1.25
1.25
1.25
1.15
1.25
1.25
1.25
1.25
Power
CW
5
10
10
30
40
80
125
100
200
Power
Peak
0.10KW
0.25KW
1KW
1KW
2KW
4KW
4KW
2KW
4KW
FREQ.
GHz
DC-4.0
DC-2.0
DC-4.0
DC-4.0
DC-2.5
DC-1.0
DC-1.0
DC-2.0
DC-1.0
KEY:
Inches[Millimeters] .XX ±.03 .XXX ±.010 [.X ±0.8 .XX ±0.25]
60 South Jefferson Road, Whippany, NJ 07981
s
Tel: 973-887-8100
s
Fax: 973-884-0445
E-Mail: sales@mcekdi-resistor.com
s
See us on the web @ www.mcekdi-resistor.com
8/02
