RF1891
Carrier Aggregation Antenna Switch
Module (SP12T + 9T)
Product Features
The RF1891 Antenna Switch Module offers very low insertion
loss along with excellent linearity performance. The RF1891 is
ideal for multi-mode GSM, EDGE, UMTS, and LTE Carrier
Aggregation capable handset applications. This module
integrates low pass filtering on the GSM transmit paths, thus
avoiding the need for external harmonic attenuation. The
RF1891 is compatible with standard RFFE control bus logic
and is packaged in a compact 2.8 mm x 3.6 mm x 0.98 mm
(max), 28-pin module package.
Package: 28 pin, 2.8mm x 3.6mm x 0.98mm (max)
Key Features
•
Excellent insertion loss and isolation performance
•
19 linear paths offer band combination and air interface
flexibility
•
Excellent GSM TX harmonic attenuation
•
B17 3F
o
Harmonic Notch Filter achieving –114 dBm (typical)
on all LB paths
•
Integrated antenna ESD protection
•
RFFE interface with standard control voltage
•
Broadband performance suitable for all cellular modulation
schemes up to 2.7 GHz
•
Very low current consumption
•
Compact 2.8 mm x 3.6 mm x 0.98 mm (max)
laminate module
•
Very high linearity and excellent harmonic
performance – ideally suited for LTE applications.
•
No External DC Blocking Capacitors Required on RF Paths
Unless DC is Applied Externally
Functional Block Diagram
Applications
•
Cellular Handset Applications
•
Cellular Modems and USB devices
•
Multi-Mode GSM, EDGE, WCDMA, LTE, and TD-SCDMA
Applications
Ordering Information
Part Number
RF1891SB
RF1891SR
RF1891TR13-5K
RF1891DK
Description
Sample Bag with 5 pcs
Sample Reel with 100 pcs
Standard 13” Reel with 5,000 pcs
Design Kit
RF1891 Rev.I | Subject to change without notice
1 of 20
www.qorvo.com
RF1891
Carrier Aggregation Antenna SwitchModule (SP12T + 9T)
Absolute Maximum Ratings
Parameter
V
DD
Supply
SCLK, SDATA & V
IO
Supply
Maximum Input Power
TXHB Port (GSM 1800/1900)
TXLB Port (GSM 850/900)
TRxHB (1 – 11) Peak Instantaneous Power
TRxLB (1 – 8) Peak Instantaneous Power
Operating Temperature
Storage Temperature
+34 @ 50% DC (T
AMB
= 25 °C)
+36 @ 50% DC (T
AMB
= 25 °C)
+31 (T
AMB
= 25 °C, 50 ohm)
+31 (T
AMB
= 25 °C, 50 ohm)
-30 to +90
-45 to +125
dBm
dBm
dBm
dBm
°C
°C
Rating
6.0
3.0
Unit
V
V
Exceeding any one or a combination of the Absolute Maximum Rating conditions may cause permanent damage to the device. Extended application of Absolute Maximum
Rating conditions to the device may reduce device reliability. Specified typical performance or functional operation of the device under Absolute Maximum Rating conditions is
not implied.
Nominal Operating Parameters
Parameter
Specification
Min.
Typ.
Max.
Unit
Condition
Nominal conditions unless otherwise stated.
V
DD
= 2.85 V, Temp. = 25 °C, All RF ports
terminated in 50 Ω. (including unused RF ports)
2.4
1.65
2.85
67
1.8
3
0.8 x V
IO
0
3
1
32
0
0.45
5.5
100
1.95
10
V
IO
0.2 x V
IO
V
μA
V
μA
V
V
μA
μs
μs
V
Measure at 10% to 90% RF after end of
RFFE message
Measured from point of V
DD
> 2.4 volts
Minimum V
IO
voltage required to reset all registers
Active Mode
Active Mode
DC and Electrical Specs
V
DD
Switch Supply Voltage
V
DD
Supply Current
V
IO
Switch Supply Voltage
V
IO
Supply Current
SCLK, SDATA –
Control Voltage HIGH
SCLK, SDATA –
Control Voltage LOW
Control Current
Switching Speed
Turn On – Time
Register RESET ( V
IO
)
RF1891 Rev.I | Subject to change without notice
2 of 23
www.qorvo.com
RF1891
Carrier Aggregation Antenna SwitchModule (SP12T + 9T)
Parameter
Specification
Min.
Typ.
Max.
Unit
Condition
Nominal conditions unless otherwise stated.
V
DD
= 2.85 V, Temp. = 25 °C, All RF ports terminated in
50 Ω. (including unused RF ports)
UMTS TRxHB1 – TRxHB11
Mid Band
Insertion Loss
TRxHB (1 thru 11) to ANTHB
Isolation ( to all TRx ports )
Port to Port
ANTHB to ANTLB
Harmonics (High Band )
TRxHB (1 thru 11) to ANTHB, 2F
o
TRxHB (1 thru 11) to ANTHB, 3F
o
IP2 – UMTS mode (B2)
TRxHB (1 thru 11)
IP3 – UMTS mode (B2)
TRxHB (1 thru 11)
VSWR
UMTS TRxLB1 – TRxLB8
Low Band
Insertion Loss
TRxLB (1 thru 8) to ANTLB
Isolation ( to all TRx ports )
Port to Port
ANTHB – ANTLB
Harmonics (Low Band)
TRxLB (1 thru 8) to ANTLB, 2F
o
TRxLB (1 thru 8) to ANTLB, 3F
o
IP2 – UMTS mode (B5)
TRxLB (1 thru 8)
IP3 – UMTS mode (B5)
TRxLB (1 thru 8)
VSWR
LTE TRxHB1 – TRxHB11
High Band
Insertion Loss
TRxHB (1 thru 11) to ANTHB
Isolation ( to all TRx ports )
Port to Port
ANTHB to ANTLB
30
dB
Refer to High Band Isolation Matrix
2300 MHz to 2690 MHz
0.88
dB
2300 MHz to 2690 MHz (B7, B38, B40, B41)
73
1.35:1
dBm
F1 = 835 MHz @ 20 dBm, F2 = 790 MHz
@ -15 dBm, Rx = 880 MHz
699 MHz to 960 MHz
121
dBm
F1 = 835 MHz @ 20 dBm, F2 = 45 MHz
@ -15 dBm, Rx = 880 MHz
126
136
dBc
dBc
Pin = +25 dBm, CW, F
o
= 824 to 849 MHz
Pin = +25 dBm, CW, F
o
= 824 to 849 MHz
49
dB
Refer to Low Band Isolation Matrix
699 MHz to 960 MHz
0.68
dB
699 MHz to 960 MHz
(B5, B6, B8, B12-B14, B17-B20, B26-B28, B44)
71
1.2:1
dBm
F1 = 1880 MHz @ +20 dBm, F2 = 1800 MHz
@ -15 dBm, Rx = 1960 MHz
1710 MHz to 2200 MHz
130
dBm
F1 = 1880 MHz @ +20 dBm, F2 = 3840 MHz
@ -15 dBm, Rx = 1960 MHz
113
118
dBc
dBc
Pin = +25 dBm, CW, F
o
= 1880 to 1910 MHz
Pin = +25 dBm, CW, F
o
= 1880 to 1910 MHz
33
dB
Refer to Mid Band Isolation Matrix
1710 MHz to 2200 MHz
0.77
dB
1710 MHz to 2200 MHz
(B1-B4, B9, B10, B23, B25, B33-B37, B39)
RF1891 Rev.I | Subject to change without notice
3 of 23
www.qorvo.com
RF1891
Carrier Aggregation Antenna SwitchModule (SP12T + 9T)
Parameter
Specification
Min.
Typ.
Max.
Unit
Condition
Nominal conditions unless otherwise stated.
V
DD
= 2.85 V, Temp. = 25 °C, All RF ports terminated in
50 Ω. (including unused RF ports)
LTE TRxHB1 – TRxHB11
High Band (Continue)
Harmonics (High Band )
TRxHB (1 thru 11) to ANTHB
TRxHB (1 thru 11) to ANTHB
IP2 – LTE (B7)
TRxHB (1 thru 11)
IP3 – LTE (B7)
TRxHB (1 thru 11)
VSWR
LTE TRxHB1 – TRxHB11
High Band
Insertion Loss
TRxHB (1 thru 11) to ANTHB
@TRxHB6
@TRxHB7
@TRxHB11
Isolation ( to all TRx ports )
Port to Port
ANTHB to ANTLB
VSWR
TRxHB6, HB7,HB11
LTE TRxLB1 – TRxLB8
Low Band
Harmonics (Low Band)
TRxLB to ANTLB, 2F
o
TRxLB to ANTLB, 3F
o
TRxLB to ANTLB, 2F
o
TRxLB to ANTLB, 2F
o
TRxLB to ANTLB, 3F
o
Triple Beat Ratio ( TBR )
TRxLB1 to TRxLB8
BC0 (GSM800)
TRxHB1 to TRxHB11
BC1 (PCS)
BC4
BC14 (PCS)
BC15 (AWS)
81
81
81
81
93
92
93
101
dBc
dBc
dBc
dBc
VSWR = 2:1, all phase angles
VSWR = 2:1, all phase angles
VSWR = 2:1, all phase angles
VSWR = 2:1, all phase angles
81
100
dBc
VSWR = 2:1, all phase angles
-103
-113
-99
-94
-110
dBm
dBm
dBm
dBm
dBm
Pin = 25 dBm, CW, F
o
= 910 MHz, LTE Band 8
Pin = 25 dBm, CW, F
o
= 880 MHz, LTE Band 8
Pin = 25 dBm, CW, F
o
= 786.5 MHz, LTE Band 13
Pin = 25 dBm, CW, F
o
= 704 MHz,
LTE Band 12, Band 17
Pin = 25 dBm, CW, F
o
= 704 MHz,
LTE Band 12, Band 17
3:1
5
At Ant HB reference.
30
dB
Refer to 3GHz Isolation Matrix
3400MHz to 3800MHz
2.76
3.07
2.8
2.41
4.5
4.5
4.5
dB
dB
dB
dB
3400MHz to 3800MHz (B22, B42, B43)
71
1.2:1
dBm
F1 = 2500 MHz @ +20 dBm, F2 = 2380 MHz
@ -15 dBm, Rx = 2620 MHz
118
dBm
F1 = 2500 MHz @ +20 dBm, F2 = 120 MHz
@ -15 dBm, Rx = 2620 MHz
113
132
dBc
dBc
Pin = +25 dBm, CW, F
o
= 2500 to 2570 MHz
Pin = +25 dBm, CW, F
o
= 2500 to 2570 MHz
RF1891 Rev.I | Subject to change without notice
4 of 23
www.qorvo.com
RF1891
Carrier Aggregation Antenna SwitchModule (SP12T + 9T)
Specification
Min.
Typ.
Max.
Parameter
Unit
Condition
Nominal conditions unless otherwise stated.
V
DD
= 2.85 V, Temp. = 25 °C, All RF ports terminated in
50 Ω. (including unused RF ports)
GSM 1800/1900 Transmit
Frequency Range (GSM1800)
Frequency Range (GSM1900)
Insertion Loss
TXHB – ANTHB
TXHB – ANTHB
Attenuation
TXHB – ANTHB, 2F
o
TXHB – ANTHB, 3F
o
TXHB – ANTHB, > 3F
o
Isolation
TXHB to TRx Ports
ANTHB – ANTLB
Harmonics
TXHB – ANTHB, 2F
o
TXHB – ANTHB, 3F
o
VSWR
GSM 850/900 Transmit
Frequency Range (GSM850)
Frequency Range (GSM900)
Insertion Loss
TXLB – ANTLB
TXLB – ANTLB
Attenuation
TXLB – ANTLB, 2F
o
TXLB – ANTLB, 3F
o
TXLB – ANTLB, > 3F
o
Isolation
TXLB to TRx Ports
ANTHB – ANTLB
Harmonics
TXLB – ANTLB, 2F
o
TXLB – ANTLB, 3F
o
VSWR
109
126
1.25:1
dBc
dBc
Pin = 35 dBm, 25% Duty cycle,
F
o
= 824 MHz to 849MHz
Pin = 35 dBm, 25% Duty cycle,
F
o
= 824 MHz to 849MHz
49
dB
Refer to Low Band Isolation Matrix
824 MHz to 915 MHz
46
50
24
dB
dB
dB
1648 MHz to 1830 MHz
2472 MHz to 2745 MHz,
2745 MHz to 12750 MHz
0.96
1.09
dB
dB
824 MHz to 849 MHz
880 MHz to 915 MHz
824
880
836.5
897.5
849
915
MHz
MHz
94
98
1.15:1
dBc
dBc
Pin = 32 dBm, 25% Duty cycle,
F
o
= 1710 MHz to 1785 MHz
Pin = 32 dBm, 25% Duty cycle,
F
o
= 1710 MHz to 1785 MHz
33
dB
Refer to Mid Band Isolation Matrix
1710 MHz to 1910 MHz
39
30
42
dB
dB
dB
3420 MHz to 3820 MHz
5130 MHz to 5730 MHz
5730 Mz to 12750 MHz
0.95
1.03
dB
dB
1710 MHz to 1785 MHz
1850 MHz to 1910 MHz
1710
1850
1747.5
1880
1785
1910
MHz
MHz
RF1891 Rev.I | Subject to change without notice
5 of 23
www.qorvo.com
