SENSITRON
___
SEMICONDUCTOR
Your Power Solutions Provider
1N5615/US thru 1N5623/US
Standard
FAST RECOVERY
RECTIFIERS
______________________________________________________________________________________
TECHNICAL DATA
A
VAILABLE AS
DATA SHEET 5081 REV. A.1
1N
JAN
JANTX
JANTXV
EQUIVALENT (SJ,SX,SV)*
JANS
SPACE EQUIVALENT SS*
Fast Recovery Rectifiers
*Sensitron equivalent diodes are manufactured and screened to MIL-PRF-19500 flow and guidelines starting from wafer
fabrication through assembly and testing using our internal specification.
DESCRIPTION:
This voidless hermetically sealed standard recovery rectifier diode series is military qualified per
MIL-PRF-19500/429 and is targeted for commerical and military aircraft, military vehicles, space,
shipboard markets and all high reliability and space applications.
FEATURES / BENEFITS
Hermetic, non-cavity glass package
Category I Metallurgically bonded
JAN/ JANTX/JANTXV available per
MIL-PRF-19500/429
Tin/Lead hot solder dip ( HSD) termination
finish
MAXIMUM RATINGS
Operating and Storage Temperature: -65 C to +175 C
Solder temperature: 260 C for 10s (max)
Thermal Resistance: 38 C (junction to lead)
Thermal Resistance: 13 C (junction to endcap)
Forward surge current: 30A @ 8.3 ms half-sine
o
o
o
o
o
ELECTRICAL CHARACTERISTICS
TYPE
NUMBER
PEAK
INVERSE
VOLTAGE
MIN
BREAKDOWN
VOLTAGE
AVG
RECTIFIED
CURRENT
Amps
55 C
100 C
MAXIMUM
REVERSE
CURRENT
@ PIV
Amps
25 C
100 C
MAX. PEAK
FORWARD
VOLTAGE
(PULSED)
VF @ 3A
V
0.8 min
1.6 max
MAX.
SURGE
CURRENT
1
IFSM
Amps
MAXIMUM
REVERSE
RECOVERY
TIME
2
Trr
nsec
150
150
250
300
500
1N5615/US
1N5617/US
1N5619/US
1N5621/US
1N5623/US
Volts
200
400
600
800
1000
Volts
220
440
660
880
1100
1.0
.750
.5
25
25
Note 1: I
o
= 1A, 8ms surge
Note 2: I
F
=0.5A, I
RM
=1A, I
r(REC)
=.25A
©2010 Sensitron Semiconductor 221 West Industry Court
Deer Park, NY 11729-4681
Phone (631) 586 7600 Fax (631) 242 9798 www.sensitron.com sales@sensitron.com
SENSITRON
___
SEMICONDUCTOR
Your Power Solutions Provider
1N5614/US thru 1N5622/US
Standard
RAFAST RECOVERY
UL T
ST ANDARD RECOVERY
RECTIFIERS
RECTIFIERS
______________________________________________________________________________________
TECHNICAL DATA
DATA SHEET 5081 REV. A.1
PACKAGE DIMENSIONS (inches/mm)
0.033 (.84
0.026 .66)
.110 (2.79
.065 1.65)
.225 (5.72
.130 3.30)
1.30 (33.0
1.00 25.4)
PKG.102
Termination Finish:
Axial leads and
Endcaps are copper with Tin/Lead finish.
©2010 Sensitron Semiconductor 221 West Industry Court
Deer Park, NY 11729-4681
Phone (631) 586 7600 Fax (631) 242 9798 www.sensitron.com sales@sensitron.com
SENSITRON
___
SEMICONDUCTOR
Your Power Solutions Provider
1N5614/US thru 1N5622/US
Standard
RAFAST RECOVERY
UL T
ST ANDARD RECOVERY
RECTIFIERS
RECTIFIERS
______________________________________________________________________________________
TECHNICAL DATA
DATA SHEET 5081 REV. A.1
PART ORDERING INFORMATION
The following part numbers can be purchased in either axial or surface mount devices and screened and tested to
the military screening flow. The parts are marked in accordance with the testing performed, example:
Sensitron Screening Level
1N
JAN
SJ
JANTX
SX
JANTXV
SV
JANS
SS
*Parts can also be ordered Tape & Reel
*Part Number--
Leaded Package
(example for 1N5615)
1N5615
JAN1N5615
SJ5615
JANTX1N5615
SX5615
JANTXV1N5615
SV5615
JANS1N5615
SS5615
*Part Number--
Surface Mount Package
(example for 1N5615US)
1N5615US
JAN1N5615US
SJ5615US
JANTX1N5615US
SX5615US
JANTXV1N5615US
SV5615US
JANS1N5615US
SS5615US
DISCLAIMER:
1- The information given herein, including the specifications and dimensions, is subject to change without prior notice to improve product
characteristics. Before ordering, purchasers are advised to contact the Sensitron Semiconductor sales department for the latest version of the
datasheet(s).
2- In cases where extremely high reliability is required (such as use in nuclear power control, aerospace and aviation, traffic equipment,
medical equipment , and safety equipment) , safety should be ensured by using semiconductor devices that feature assured safety or by
means of users’ fail-safe precautions or other arrangement .
3- In no event shall Sensitron Semiconductor be liable for any damages that may result from an accident or any other cause during operation of
the user’s units according to the datasheet(s). Sensitron Semiconductor assumes no responsibility for any intellectual property claims or any
other problems that may result from applications of information, products or circuits described in the datasheets.
4- In no event shall Sensitron Semiconductor be liable for any failure in a semiconductor device or any secondary damage resulting from use at
a value exceeding the absolute maximum rating.
5- No license is granted by the datasheet(s) under any patents or other rights of any third party or Sensitron Semiconductor.
6- The datasheet(s) may not be reproduced or duplicated, in any form, in whole or part, without the expressed written permission of Sensitron
Semiconductor.
7- The products (technologies) described in the datasheet(s) are not to be provided to any party whose purpose in their application will hinder
maintenance of international peace and safety nor are they to be applied to that purpose by their direct purchasers or any third party. When
exporting these products (technologies), the necessary procedures are to be taken in accordance with related laws and regulations.
