This document was generated on 06/08/2010
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Description:
0190690241
Active
Krimptite™ Ring Tongue Terminal for 10-12 AWG Wire, Stud Size 3/8", Length
26.82mm (1.056")
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
Agency Certification
CSA
UL
LR18689
E32244
Series
image - Reference only
EU RoHS
China RoHS
ELV and RoHS
Compliant
REACH SVHC
Contains SVHC: No
Halogen-Free
Status
Halogen-Free
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
General
Product Family
Series
Crimp Quality Equipment
Mil-Spec
MolexKits
Product Name
Type
Ring and Spade Terminals
19069
Yes
N/A
Yes
Krimptite™
Ring
Physical
Barrel Type
Insulation
Material - Plating Mating
Packaging Type
Plating min: Mating (µin)
Plating min: Mating (µm)
Plating min: Termination (µin)
Plating min: Termination (µm)
Stud Size
Wire Size AWG
Wire Size mm²
Closed
None
Tin
Bag
100
2.5
100
2.5
3/8" (M9)
10, 12
4.00 - 6.00
Search Parts in this Series
19069Series
Application Tooling
|
FAQ
Tooling specifications and manuals are
found by selecting the products below.
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Global
Description
Product #
Hand Crimp Tool
0640030100
Crimp Head for the 0640070100
AT-200™ Pneumatic
Hand Tool
Material Info
Old Part Number
C-140-38
Reference - Drawing Numbers
Sales Drawing
CCD10101
This document was generated on 06/08/2010
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
