714155384 Product Details
Industrial Relays (General Purpose)
Always EU RoHS compliant but not ELV Compliant
(
Find RoHS Compliant
Alternates
/
Statement of Compliance
)
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
714155384
TE Internal Number: 714155384
Product Highlights:
RM 2/3/7 Series
Contact Current Class = 5A to 10A Class, Less Than
16A
Contact Rated Current = 10 A
Terminal Type = Plugin, Quick Connect
Contact Arrangement = 3 Form C (CO)
View all Features
Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
Product Line Information
Related Products:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Electrical Characteristics:
Contact Current Class = 5A to 10A Class, Less Than 16A
Contact Rated Current (A) = 10
Contact Limiting Continuous Current (A) = 10
Contact Limiting Making Current (A) = 40
Contact Limiting Breaking Current (A) = 10
Insulation Initial Dielectric Between Coil/Contact Class = 1500V to
2500VA Class
Insulation Initial Dielectric Between Open Contacts (V rms) = 1500
Insulation Initial Dielectric Between Contacts and Coil (V rms) =
2500
Contact Rated Voltage (VAC) = 400
Contact Switching Voltage Max. (VAC) = 440
Contact Limiting ShortTime Current (A) = 10
Contact Switching Recommended Load, Min. = 100mA at 24V
Coil Rated Voltage (VDC) = 48
Coil Resistance (Ω) = 2000
Coil Rated Power, DC (mW) = 1200
Coil Rated Power Class = 1W to 1.5W Class
Insulation Initial Dielectric Between Adjacent Contacts (V rms) =
2500
Insulation Creepage Class = >8mm Class
Insulation Clearance Class = 2.5mm to 4mm Class
Insulation Special Features = 4000V Initial Surge Withstand Voltage
between Contacts and Coil
Dimensions:
Mechanical Length Class = 35mm to 40mm Class
Length (mm [in]) = 38.50 [1.515]
Mechanical Width Class = 30mm to 40mm Class
Width (mm [in]) = 35.50 [1.398]
Mechanical Height Class = 40mm to 50mm Class
Height (mm [in]) = 48.50 [1.909]
Insulation Clearance Between Contact and Coil (mm [in]) = 4
[0.157]
Insulation Creepage Between Contact and Coil (mm [in]) = 14.9
[0.587]
Body Features:
Mount Type = Bracket
Weight (g [oz]) = 81.00 [2.859]
Contact Features:
Terminal Type = Plugin, Quick Connect
Contact Material = AgCdO
Contact Number of Poles = 3
Configuration Features:
Contact Arrangement = 3 Form C (CO)
Coil Magnetic System = Monostable, DC
Coil Special Features = UL Coil Insulation Class B
Industry Standards:
RoHS/ELV Compliance = RoHS/Not ELV Compliant
Lead Free Solder Processes = Not relevant for lead free process
RoHS/ELV Compliance History = Always was RoHS not ELV compliant
Approved/Registered Standards = cULus, VDE
Environmental:
Environmental Category of Protection = RTI
Environmental Ambient Temperature, Max. (°C [°F]) = 60 [140]
Environmental Ambient Temperature Class = 50°C to 70°C Class
Packaging Features:
Packaging Method = Tray
Other:
Series = RM 2/3/7
Brand = Schrack
Additional Features = Mechanical Indicator
