RS1501 thru RS1507
SINGLE-PHASE SILICON BRIDGE
CHENG- YI
ELECTRONIC
VOLTAGE RANGE
50 TO 1000 VOLTS
CURRENT
15.0 Amperes
FEATURES
Low leakage
Low forward voltage
Mounting Position: Any
Surge overload rating:250 amperes peak
Siliver-plated copper leads
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
0
C ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
MAXIMUM RATINGS
(At T
A
=25
0
C unless otherwise noted)
RATINGS
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Bridge Input Voltage
Maximum DC Blocking Voltage
Maximum Average Forward
Output Current at @
TC=50 C
0
RS1501
RS1502
100
70
100
RS1503
200
140
200
RS1504
400
280
400
15
RS1505
600
420
600
RS1506
800
560
800
RS1507
1000
700
1000
UNITS
V
V
V
A
V
RRM
V
RMS
V
DC
I
O
50
35
50
Peak Forward Surge Current 8.3ms single
half sine-wave superimposed on rated load
Operating and Storage Temperature Range
Maximum Forward Voltage drop per element of 7.5A DC
I
FSM
T
J
250
A
T
STG
V
F
I
R
-55 to +150
1.05
10
0.2
0
C
V
Maximum Reverse Current at Rated
DC Blocking Voltage per element
@ TA=25
0
C
@ TA=100 C
0
A
mA
RS1501 thru RS1507
SINGLE PHASE GLASS BRIDGE
CHENG- YI
ELECTRONIC
RATING AND CHARACTERISTICS CURVES
RS1501 THRU RS1507
Fig. 1
-
MAXIMUM FORWARD SURGE CURRENT
Fig. 4
-
MAXIMUM NON-REPETITIVE SURGE CURRENT
250
AVERAGE FORWARD OUTPUT
CURRENT AMPERES
15
200
150
100
0
TJ=150C
single half sine-wave
(JEDEC Method)
12
9
50
6
60Hz RESISTIVE OR
INDUCTIVE LOAD
25
50
75
100
125
150
10
3
CASE TEMPERATURE,
0
C
1
2
5
10
20
50
100
NUMBER OF CYCLES AT 60 Hz
Fig. 2 - TYPICAL FORWARD
CHARACTERISTICS
INSTANTANEOUS FORWARD CURRENT. AMPERES
10
0
TJ=150C
Fig. 5
-
TYPICAL REVERSE
1.0
1000
CHARACTERISTICS
TJ=25
0
C
0
TJ=150C
0.1
0
TJ=125C
.001
0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
100
INSTANTANEOUS FORWARD VOLT
AGE, VOLTS
0
TJ=100C
Fig. 3 - TYPICAL JUNCTION CAPACITANCE
100
10
TJ=25
0
C
f=1.0MHz
1.0
TJ=25
0
C
CAPACITANCE, pF
50
.01
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE
10
1
4
10
100
REVERSE VOLTAGE, VOLTS
