Table 2 . Optical characteristics for LUXEON 3030 2D Line at 120mA, T
j
=25ºC .
Part numBEr
L130-xxxx003000x21
tyPIcal total IncluDED anGlE
[1]
140°
tyPIcal VIEWInG anGlE
[2]
116°
Notes for Table 2:
1.
Total angle at which 90% of total luminous flux is captured.
2.
Viewing angle is the off axis angle from lamp centerline where the luminous intensity is ½ of the peak value.
Electrical and Thermal Characteristics
Table 3 . Electrical and thermal characteristics for LUXEON 3030 2D Line at 120mA, T
j
=25ºC .
Part numBEr
L130-xxxx003000x21
ForWarD VoltaGE
[1]
(V
f
)
mInImum
5.8
tyPIcal
6.0
maXImum
6.6
tyPIcal tEmPEraturE
coEFFIcIEnt oF ForWarD
VoltaGE
[2]
(mV/°c)
-2.0 to -4.0
tyPIcal thErmal
rEsIstancE—JunctIon
to solDEr PaD (°c/W)
12.0
Notes for Table 3:
1.
Lumileds maintains a tolerance of ±0.1V on forward voltage measurements.
2.
Measured between 25°C and 85°C.
Absolute Maximum Ratings
Table 4 . Absolute maximum ratings for LUXEON 3030 2D Line .
ParamEtEr
DC Forward Current
[1]
Peak Pulsed Forward Current
[2]
ESD Sensitivity (ANSI/ESDA/JEDEC JS-001-2012)
LED Junction Temperature (DC & Pulse)
Operating Case Temperature
LED Storage Temperature
Soldering Temperature
Allowable Reflow Cycles
Reverse Voltage (V
reverse
)
[3]
maXImum PErFormancE
240mA
300mA
Class 2
125°C
-40°C to 105°C
-40°C to 105°C
JEDEC 020D 260°C
3
-5V
Notes for Table 4:
1.
Residual periodic variations due to power conversion from alternating current (AC) to direct current (DC), also called “ripple”, are acceptable if the following conditions are met:
– The frequency of the ripple current is 100Hz or higher
– The average current for each cycle does not exceed the maximum allowable DC forward current
– The maximum amplitude of the ripple does not exceed 25% of the maximum allowable DC forward current
2.
Pulse operation with the maximum peak pulse forward current is acceptable if the pulse on time is ≤5ms per cycle and the duty cycle is ≤50%
3.
At a maximum reverse current of 10µA. LUXEON 3030 2D LEDs are not designed to be driven in reverse bias.
