ECQE12183JE

Description
Film Capacitor, Polyester, 1250V, 5% +Tol, 5% -Tol, 0.018uF, Through Hole Mount, RADIAL LEADED
CategoryPassive components    capacitor
File Size166KB，7 Pages
ManufacturerPanasonic
Websitehttp://www.panasonic.co.jp/semicon/e-index.html
Environmental Compliance
Download Datasheet Parametric View All

ECQE12183JE Overview

Film Capacitor, Polyester, 1250V, 5% +Tol, 5% -Tol, 0.018uF, Through Hole Mount, RADIAL LEADED

ECQE12183JE Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerPanasonic
package instruction,
Reach Compliance Codeunknown
ECCN codeEAR99
capacitance0.018 µF
Capacitor typeFILM CAPACITOR
dielectric materialsPOLYESTER
JESD-609 codee3
Installation featuresTHROUGH HOLE MOUNT
negative tolerance5%
Number of terminals2
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Package shapeRECTANGULAR PACKAGE
method of packingAMMO PACK
positive tolerance5%
Rated (AC) voltage (URac)125 V
Rated (DC) voltage (URdc)1250 V
surface mountNO
Terminal surfaceTin (Sn)
Terminal shapeWIRE

ECQE12183JE Preview

Plastic Film Capacitors
Metallized Polyester Film Capacitor
Type:
ECQE(F)
Non-inductive construction using metallized Polyester
film with flame retardant epoxy resin coating
sFeatures
•
Self-healing property
•
Excellent electrical characteristics
•
Flame retardant epoxy resin coating
sRecommended
Applications
•
General purpose usage
.
.
!
Please contact us when applications are CD , ignitor etc.
..
sExplanation
of Part Numbers
1
2
3
4
5
6
7
8
9
10
11
12
E
C
Q
E
Rated volt.
Capacitance
F
Cap. Tol. Suffix
Suffix
Product code
Dielectric &
construction
1
2
4
6
100VDC
250VDC
400VDC
630VDC
10
12
1A
2A
1000VDC
1250VDC
125VAC
250VAC
J
K
M
±
5
%
±
10
%
±
20
%
Blank
B
W
3
6
9
Type 1
Type 2
Type 3
Ammo
Ammo
Reel
Straight
Crimped lead
Crimped taping
Crimped taping
Crimped taping
q
Explanation of Part Number for Odd Size Taping
E
C
Q
E
Rated volt.
Capacitance
R
Suffix Cap. Tol. Suffix
Product code
Dielectric &
construction
sSpecifications
Category temp. range
(Including temperature-rise on unit surface)
Rated voltage
Capacitance range
Capacitance tolerance
Dissipation factor
– 40 to + 105˚C
100VDC, 250VDC,400VDC, 630VDC, 1000VDC, 1250VDC,125VAC, 250VAC
(Derating of rated voltage by 1.25%/˚C at more than 85˚C)
0.001 to 10µF(E-12)
±5%(J), ±10%(K), ±20%(M)
1.0%max. (20˚C, 1kHz)
•
Rated volt. 100V to 630VDC
Between terminals : Rated volt.(VDC)
!
150% 60s
•
Rated volt. 1000VDC,1250VDC
Between terminals : Rated volt.(VDC)
!
175% 2 to 5s or 1000VAC 60s
Between terminals to enclosure : 1500VAC 60s
•
Rated volt. 125VAC, 250VAC
Between terminals : Rated volt.(VAC)
!
230% 60s
Between terminals to enclosure : 1500VAC 60s
100V to 630VDC:
C
<
0.33µF : 9000MΩmin.
=
(20˚C, 100VDC 60s)
C > 0.33µF : 3000MΩ . µFmin.
1000VDC, 1250VDC:
10000MΩmin. (20˚C, 100VDC 60s)
2000MΩmin. (20˚C, 500VDC 60s)
125VAC, 250VAC:
2000MΩmin. (20˚C, 500VDC 60s)
Withstand voltage
Insulation resistance
Design, Specifications are subject to change without notice.
Ask factory for technical specifications before purchase and/or use.
Whenever a doubt about safety arises from this product, please inform us immediately for technical consultation without fail.
Plastic Film Capacitors
sDimensions
