09-50-7041 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 09-50-7041

09-50-7041: Description2 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER; CategoryThe connector; File Size31KB，3 Pages; ManufacturerMolexKits; Websitehttp://www.molexkits.com

Download Datasheet Parametric Compare View All

09-50-7041 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	09-50-7041	-	-	View	Buy Now

09-50-7041 Overview

2 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER

09-50-7041 Parametric

Parameter Name	Attribute value
Contact materials	BRASS
Terminal spacing	3.96 mm
Total number of contacts	2
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
Options	GENERAL PURPOSE
Manufacturer Series	41662
Contact surface matching	tin
Contact coated terminals	tin
Connection Type	Dual board connector
Connector male and female	Pin
collocation information	MULTIPLE MATING PARTS AVAILABLE
Installation method	right angle
Installation type	BOARD
Number of load rows	1
Terminal type	welding
UL flammability code	94V-0

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0010

General Information

Part Number:

76650-0010

Manufacturer:

Title:

Description:

Product Family:

Certificates:

Molex / Waldom

KK-156 Connector Kit

Vertical and Right Angle Header and Receptacle, with Extraction and Premium

Crimp Tool

KK™

(Molex parts within this kit) - EU and China RoHS, UL and CSA

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Mounting

Orientation:

Circuit Sizes:

Current Rating:

Voltage:

Wire size:

Product Highlights

The KK system of "building block" connectors can be used to create thousands of

different configurations, allowing each user to build a system that is precisely suited

to their application. KK has become known as a versatile interconnecting system

developed to meet the challenge of modularization.

Features and Benefits

• Standard cantilever terminals

• Cantilever design provides high contact

pressure

• Wiping action cleans oxides when

connector is mated

Applications

• Vending and Gaming Machines

• Production Equipment

• Industrial Instruments

• Energy and Power

Wire-to-Board

3.96mm (.156")

Receptacle and Header

Vertical and Right Angle

2, 3, 4, 5, 6 and 10

(4.75 - 5) Amps Dependant on AWG

250 Volts

20-18 AWG

For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com

Page 1 of 3

09-50-7041 Related Products

	09-50-7041	09-50-7101	26-48-1022	26-48-1041	26-48-1062	76650-0010
Description	2 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER	2 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER	2 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER	2 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER	2 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER	2 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER
Contact materials	BRASS	BRASS	BRASS	BRASS	BRASS	BRASS
Terminal spacing	3.96 mm	3.96 mm	3.96 mm	3.96 mm	3.96 mm	3.96 mm
Total number of contacts	2	2	2	2	2	2
Lead-free	Yes	Yes	Yes	Yes	Yes	Yes
EU RoHS regulations	Yes	Yes	Yes	Yes	Yes	Yes
state	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Manufacturer Series	41662	41662	41662	41662	41662	41662
Contact surface matching	tin	tin	tin	tin	tin	tin
Contact coated terminals	tin	tin	tin	tin	tin	tin
Connection Type	Dual board connector	Dual board connector	Dual board connector	Dual board connector	Dual board connector	Dual board connector
Connector male and female	Pin	Pin	Pin	Pin	Pin	Pin
collocation information	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE
Installation method	right angle	right angle	right angle	right angle	right angle	right angle
Installation type	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD
Number of load rows	1	1	1	1	1	1
Terminal type	welding	welding	welding	welding	welding	welding
UL flammability code	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0
