223AT Overview

1 CHANNEL DARLINGTON OUTPUT OPTOCOUPLER

223AT Parametric

Parameter NameAttribute value
Maximum operating temperature100 Cel
Minimum operating temperature-55 Cel
Number of functions1
Processing package descriptionSOIC-8
Lead-freeYes
EU RoHS regulationsYes
China RoHS regulationsYes
stateACTIVE
terminal coatingMATTE TIN
structureSINGLE
Optoelectronic device typeDARLINGTON OUTPUT
Minimum Coll-emtr Bkdn voltage30 V
Rated current transfer ratio500 %
Maximum input control current60 mA
Maximum insulation voltage3000 V
IL221AT/222AT/223AT
Vishay Semiconductors
Optocoupler, Photodarlington Output,
Low Input Current, High Gain, with Base Connection
FEATURES
A
1
C
2
NC
3
NC
4
8
NC
7
B
6
C
5
E
• Isolation test voltage, 4000 V
RMS
• Industry standard SOIC-8 surface mountable
package
• Standard lead spacing, 0.05"
• Available only on tape and reel (conforms to
EIA standard RS481A)
• Compatible with dual wave, vapor phase and IR reflow
soldering
• Lead (Pb)-free component
• Component in accordance to RoHS 2002/95/EC and
WEEE 2002/96/EC
i179022
DESCRIPTION
The IL221AT/IL222AT/IL223AT is a high current transfer
ratio (CTR) optocoupler with a gallium arsenide infrared LED
emitter and a silicon NPN photodarlington transistor
detector.
The device has a CTR tested at 1.0 mA LED current. This
low drive current permits easy interfacing from CMOS to
LSTTL or TTL.
This optocoupler is constructed in a standard SOIC-8 foot
print which makes it ideally suited for high density
applications. In addition to eliminating through-hole
requirements, this package conforms to standards for
surface mount devices.
AGENCY APPROVALS
• UL1577, file no. E52744 system code Y
• CUL - file no. E52744, equivalent to CSA bulletin 5A
• DIN EN 60747-5-5 available with option 1
ORDER INFORMATION
PART
IL221AT
IL222AT
IL223AT
REMARKS
CTR > 100 %, SOIC-8
CTR > 200 %, SOIC-8
CTR > 500 %, SOIC-8
ABSOLUTE MAXIMUM RATINGS
PARAMETER
INPUT
Peak reverse voltage
Forward continuous current
Power dissipation
Derate linearly from 25 °C
OUTPUT
Collector emitter breakdown voltage
Emitter collector breakdown voltage
Collector base breakdown voltage
I
CMAX DC
I
CMAX
Power dissipation
Derate linearly from 25 °C
t < 1.0 ms
BV
CEO
BV
ECO
BV
CBO
I
CMAX DC
I
CMAX
P
diss
30
5.0
70
50
100
150
2.0
V
V
V
mA
mW
mW
mW/°C
V
R
I
F
P
diss
6.0
60
90
1.2
V
mA
mW
mW/°C
TEST CONDITION
SYMBOL
VALUE
UNIT
www.vishay.com
330
For technical questions, contact: optocoupler.answers@vishay.com
Document Number: 83617
Rev. 1.8, 08-May-08
