30TPS16PBF datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Trigger device> 30TPS16PBF

30TPS16PBF: DescriptionPhase Control SCR, 20 A; CategoryAnalog mixed-signal IC Trigger device; File Size138KB，7 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Environmental Compliance

Download Datasheet Parametric View All

30TPS16PBF Overview

Phase Control SCR, 20 A

30TPS16PBF Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Vishay
Parts packaging code	TO-247AC
package instruction	FLANGE MOUNT, R-PSFM-T3
Contacts	3
Reach Compliance Code	compliant
Nominal circuit commutation break time	110 µs
Configuration	SINGLE
Critical rise rate of minimum off-state voltage	500 V/us
Maximum DC gate trigger current	45 mA
Maximum DC gate trigger voltage	2 V
Maximum holding current	100 mA
JEDEC-95 code	TO-247AC
JESD-30 code	R-PSFM-T3
Maximum leakage current	0.5 mA
On-state non-repetitive peak current	250 A
Number of components	1
Number of terminals	3
Maximum on-state current	20000 A
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum rms on-state current	30 A
Off-state repetitive peak voltage	1600 V
Repeated peak reverse voltage	1600 V
surface mount	NO
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
Maximum time at peak reflow temperature	NOT SPECIFIED
Trigger device type	SCR
Base Number Matches	1

Preview

Download Datasheet

View All

30TPS16PbF High Voltage Series

Vishay High Power Products

Phase Control SCR, 20 A

DESCRIPTION/FEATURES

(A)

TO-247AC

1 (K) (G)

The 30TPS16PbF High Voltage Series of silicon

Pb-free

controlled rectifiers are specifically designed for

Available

medium power switching and phase control

RoHS*

applications. The glass passivation technology

COMPLIANT

used has reliable operation up to 125 °C junction

temperature.

Typical applications are in input rectification (soft start) and

these products are designed to be used with Vishay HPP

input diodes, switches and output rectifiers which are

available in identical package outlines.

This product has been designed and qualified for industrial

level and lead (Pb)-free (“PbF” suffix).

PRODUCT SUMMARY

at 20 A

TSM

RRM

< 1.3 V

300 A

1600 V

MAJOR RATINGS AND CHARACTERISTICS

PARAMETER

T(AV)

RMS

RRM

DRM

TSM

dV/dt

dI/dt

20 A, T

= 25 °C

TEST CONDITIONS

Sinusoidal waveform

VALUES

1600

300

1.3

500

150

- 40 to 125

V/µs

A/µs

°C

UNITS

VOLTAGE RATINGS

PART NUMBER

RRM

DRM

, MAXIMUM

REPETITIVE PEAK AND

OFF-STATE VOLTAGE

1600

RSM

, MAXIMUM

NON-REPETITIVE PEAK

REVERSE VOLTAGE

1700

RRM

DRM

AT 125 °C

30TPS16PbF

* Pb containing terminations are not RoHS compliant, exemptions may apply

Document Number: 94387

Revision: 06-Jun-08

For technical questions, contact: diodes-tech@vishay.com

www.vishay.com
