3QL100AK Overview

Package with screw terminals Glass passivated chips

3QL100AK-22 Thru 3QL100AS-22
1.
外型尺寸Feature
& Dimension
Features
l
Package with screw terminals
l
Isolation voltage 3000 V~
l
Glass passivated chips
l
Blocking voltage up to 1600 V
l
Low forward voltage drop
l
UL registered E231047
Applications
l
Supplies for DC power equipment
l
Input rectifiers for PWM inverter
l
Battery DC power supplies
l
Field supply for DC motors
Advantages
l
Easy to mount with two screws
l
Space and weight savings
l
Improved temperature and power cycling
2.
产品性½Product
Characteristic
ELECTRICAL AND THERMAL CHARACTERISTICS
Item
Maximum repetitive voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Peak Reverse Current (per leg) @Tj = 25°C
At Rated DC Blocking Voltage @Tj = 150°C
Average recified forward current 60Hz sine
wave,R-load with heatsink Tc=100℃
TJ=45℃VR=0
t=10ms (50Hz),sine
t=8.3ms(60Hz),sine
TJ=150℃ VR=0 t=10ms (50Hz),sine
t=8.3ms(60Hz),sine
TJ=45℃ VR=0
t=10ms (50Hz),sine
t=8.3ms(60Hz),sine
TJ=150℃ VR=0 t=10ms (50Hz),sine
t=8.3ms(60Hz),sine
I
FSM
Symbol
VRM
VRMS
VDC
IR
3QL100AK
800
560
800
1200
840
1200
≤10
≤8
100
1000
1080
800
860
A
TC=25°C unless otherwise specified
3QL100AO
3QL100AQ
1400
980
1400
3QL100AS
1600
1120
1600
Unit
V
V
V
uA
mA
A
Io
5000
I
2
t
5830
3200
3700
2
A
2
s
