501951-5010: Description50 CONTACT(S), FEMALE, STRAIGHT FFC/FPC CONNECTOR, SURFACE MOUNT; CategoryThe connector; File Size30KB，2 Pages; ManufacturerMolexKits; Websitehttp://www.molexkits.com

Download Datasheet Parametric Compare View All

501951-5010 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	501951-5010	-	-	View	Buy Now

501951-5010 Overview

50 CONTACT(S), FEMALE, STRAIGHT FFC/FPC CONNECTOR, SURFACE MOUNT

501951-5010 Parametric

Parameter Name	Attribute value
Contact materials	PHOSPHOR BRONZE
Terminal spacing	0.5000 mm
Total number of contacts	50
Processing package description	ROHS COMPLIANT
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
Options	GENERAL PURPOSE
Manufacturer Series	501951
Contact surface matching	gold
Contact coated terminals	gold
Connection Type	FFC/FPC connector
Connector male and female	Jack
Installation method	straight
Installation type	BOARD
Number of load rows	1
Terminal type	surface mount
UL flammability code	94V-0

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0120

General Information

Part Number:

76650-0120

Manufacturer:

Title:

Description:

Product Family:

Certificates:

Molex / Waldom

Easy-On FFC/FPC Connector Kit

SMT Vertical Header, ZIF with Flip-Type Secure Actuator

Easy-On™

(Molex parts within this kit) - EU and China RoHS Compliant, UL and CSA

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Mounting

Orientation:

Circuit Sizes:

Current Rating:

Voltage:

Product Highlights

Easy-on connectors provide a zero insertion force (ZIF) connector for use with flat

flexible cable (FFC) and flexible printed circuitry (FPC). These miniature surface

mount connectors have flip-type actuators that secure the connection between the

FFC-FPC and the connector terminals. The compact size allows them to be used in

any device where space is an issue.

FFC/FPC

0.50mm (.020")

Headers

Vertical

30, 40, 50 and 60

0.4 Amps

50 Volts

Features and Benefits

• Compact depth, height and length features

for space savings for mobile devices

• Robust terminal and actuator designs for

higher contact and cable retention

• ZIF allows for repeat cycling with low wear

• Robust solder tabs for secure PCB

retention

Applications

• Notebook PC

• PDA

• Digital Cameras

• Cellular phones

• Digital audio player

• GPS

For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com

Page 1 of 2

501951-5010 Related Products

	501951-5010	501951-4010	76650-0120	501951-6010	501951-3010
Description	50 CONTACT(S), FEMALE, STRAIGHT FFC/FPC CONNECTOR, SURFACE MOUNT	40 CONTACT(S), FEMALE, STRAIGHT FFC/FPC CONNECTOR, SURFACE MOUNT	40 CONTACT(S), FEMALE, STRAIGHT FFC/FPC CONNECTOR, SURFACE MOUNT	MOLEX - 501951-6010 - CONNECTOR; FPC; RCPT; 60POS; 2ROW	MOLEX - 501951-3010 - CONNECTOR; FPC; RCPT; 30POS; 2ROW
Contact materials	PHOSPHOR BRONZE	NOT SPECIFIED	NOT SPECIFIED	-	-
Terminal spacing	0.5000 mm	0.5000 mm	0.5000 mm	-	-
Total number of contacts	50	40	40	-	-
Lead-free	Yes	Yes	Yes	-	-
EU RoHS regulations	Yes	Yes	Yes	-	-
state	ACTIVE	ACTIVE	ACTIVE	-	-
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	-	-
Manufacturer Series	501951	501951	501951	-	-
Contact surface matching	gold	NOT SPECIFIED	NOT SPECIFIED	-	-
Contact coated terminals	gold	NOT SPECIFIED	NOT SPECIFIED	-	-
Connection Type	FFC/FPC connector	FFC/FPC connector	FFC/FPC connector	-	-
Connector male and female	Jack	Jack	Jack	-	-
Installation method	straight	straight	straight	-	-
Installation type	BOARD	BOARD	BOARD	-	-
Number of load rows	1	1	1	-	-
Terminal type	surface mount	surface mount	surface mount	-	-
UL flammability code	94V-0	94V-0	94V-0	-	-
