Datasheet for 76650-0144
General Information
Part Number:
76650-0144
Manufacturer:
Title:
Description:
Product Family:
Certificates:
Molex / Waldom
XRC Circular Sealed Connector Kit
Circular Sealed Plug and Receptacle, IP-67
XRC™
(Molex Parts within this kit) - EU and China RoHS Compliant, UL and CSA
Country of Origin:
Kit assembled in U.S.A.
Specifications
Design
Configuration:
Shell Size:
Connector Type:
Circuit Sizes:
Current Rating:
Voltage Rating:
Wire size:
Product Highlights
The XRC 14-circuit, circular connector was developed to meet the demanding
requirements of the heavy-equipment industry. For maximum design flexibility, the
XRC plugs and receptacles are available in standard and reverse gender. The
connectors can be used for in-line or panel-mount applications. Plugs feature a
quick-disconnect bayonet latch to provide quick and easy connections with reduced
installation and service time while ensuring accurate mating depth. Designed to
meet IP67 standards, XRC plugs and receptacles protect against the ingress of
dust, water and other contaminants to maintain the integrity of the mated pair.
Wire-to-Wire
standard 18 (Additional shell sizes will eventually be released)
Plugs and Receptacles
14 Circuits (maximum) (Additional circuits will eventually be released)
10 Amps (18 AWG), 13 Amps (16-14 AWG)
300 Volts
(18-16) and (18-14) AWG
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 1 of 3
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0144
Features and Benefits
• Environmentally sealed to IP67 standard
• Standard and reverse terminal genders,
allows for custom polarization
• Tactile and audible mating feedback,
facilitates reliable mating
• Bayonet-style latch, provides quick and
easy connections for reduced installation
and service time
• Simple crimp-and-poke technology, does
not require terminal alignment when
installing crimped wires
Bill of Materials for Part No. 76650-0144
Country
Molex Part No. of Origin
84501-0001
84507-0012
84502-0004
84502-0008
84590-0020
84590-0021
84590-0022
84590-0023
84590-0024
84590-0025
84508-0001
84509-0002
Description
XRC™ Sealed Plug with Pin Insert, Shell Size 18, 14
Taiwan
Circuits, Blue Ring
XRC™ Sealed Plug with Socket Insert, Shell Size 18, 14
Taiwan
Circuits, Blue Ring
Quantity in
Kit
1
1
1
1
10
10
25
25
10
10
1
5
Applications
• Marine: Boats and propulsion systems
• Agriculture Equipment, Combines, Tractors
• Transportation: Tractor trailers, Buses,
Fire Trucks
• Recreational Vehicles
• Construction Equipment: Fork lifts, Loaders,
Cranes
Taiwan
XRC™ Panel Mount Hex Nut for Shell Size 18 Receptacles
XRC™ Sealed Receptacle with Pin Insert, Shell Size 18, 14
Taiwan
Circuits, Blue Ring
Taiwan
XRC™ 3.56mm (.140") Crimp Terminal, Pin, 18-16 AWG
Taiwan
XRC™ 5.77mm (.227") Crimp Terminal, Pin, 18-14 AWG
Taiwan
XRC™ 4.64mm (.183") Crimp Terminal, Pin, 18-14 AWG
4.64mm (.183") Hooded Crimp Terminal, Socket, 18-14
Taiwan
AWG
5.77mm (.227") Hooded Crimp Terminal, Socket, 18-14
Taiwan
AWG
3.56mm (.140") Hooded Crimp Terminal, Socket, 18-16
Taiwan
AWG
XRC™ Sealed Receptacle with Socket Insert, Shell Size 18,
Taiwan
14 Circuits, Blue Ring
Taiwan
Sealing Key Plug, Contact Sizes 12 & 16
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 2 of 3
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0144
Recommended Molex Tool(s) for Part No. 76650-0144*
Country
Molex Part No. of Origin
63811-1000 *
63811-5500 *
63811-5600 *
63811-5800 *
63813-1900 *
USA
USA
USA
USA
Description
Hand Crimper - DISTRIBUTION ONLY (non-ratcheting, 24-14 AWG)
Hand Crimper Tool - (3.56mm (.140"))
Hand Crimper Tool - (4.64mm (.183"))
Hand Crimper Tool - (5.77mm (.227"))
Taiwan
Terminal Extractor Tool
*Tool(s) not included in kit. Tool(s) ordered separately.
