Features
Low Reverse Leakage
Low Forward Voltage Drop
Guard Ring for Overvoltage Protection
Isolated Hermetically Sealed Power Package
Ceramic Seals for Improved Hermeticity
Custom Lead Forming Available
Eutectic Die Attach
150°C Operating Temperature
Space Level Screening Available
Available in TO-254Z Packaging
1N6660
1N6660R
30 Amp / 45 VOLTS
COMMON CATHODE
OR
COMMON ANODE
SCHOTTKY RECTIFIER
TO-254
45V
45V
45V
Maximum Ratings (per diode)
Peak Repetitive Reverse voltage
Working Peak Reverse Voltage
DC Blocking Voltage
Average Forward Current, 25 °C
Peak Surge Forward Current @
tp
~
8.3 ms, half sinewave,
lo = 0;V
R M
=0
Peak Reverse Surge Current @
tp = 30ns, Vf?SM = 54 V min,
L = 260 nH
Thermal Resistance, Junction to Case
Thermal Resistance, Junction to
Ambient
Operating Junction Temperature
Storage Temperature
VRWM
VRRM
VR
lo
IFSM
15A
Notel
300 Apk
2A
2
('N666CR)
.545
IRRM
i
R0JC
R0ja
1.65°C/W
40°C/W
-65°C to
150°C
-65°C to
150°C
Tj
Tstg
800
r
V
i
66 i
\I 50
" 3 130
i
i
Electrical Characteristics par diode® 25°C Unless Otharwise Specified
Parameter
Symbol
Typical
MA
Test Conditions
IF = 5 A; Tj
~
25°C*
l
F
= 15A;Tj = 25°C*
IP = 30 A; Tj = 25°C*
l
F
= 15A;Tj=-55°C*
Tj = 25°C
Tj=125°C
>
045
! 035
esc
Maximum
0.55V
VF
0.75V
Instantaneous
1.0V
Forward
0.80V
Voltage
1 mA
Maximum DC
50 ^A
IH
40mA
Reverse
Current At
Rated DC
Blocking
Voltage
Junction
2000
Cj
PF
Capacitance
*Pulse test: Pulse width 300 usec, Duty cycle 2%
V
R
= 5 V, f = 1 MHz
Note:
1. Derate linearly @ 300mA/°C from Tj = T
c
= + 100
D
C to 150°C
NJ Semi-Conductors reserves itr'e right to change test conditions, parameter limits and package dimensions without
notice. Information furnished by NJ Semi-Conductors is believed to be both accurate and reliable at the time of going
to press. However, NJ Semi-Conductors assumes no responsibility for any errors or omissions discovered in its use.
NJ Semi-Conductors encourages customers to verify that datasheets are current before placing orders.
