10ZLG470MFA8X11.5 datasheet, PDF

Datasheet> All Categories > Passive components> capacitor> 10ZLG470MFA8X11.5

10ZLG470MFA8X11.5: DescriptionCAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 10V, 470uF, THROUGH HOLE MOUNT, RADIAL LEADED, ROHS COMPLIANT; CategoryPassive components capacitor; File Size77KB，3 Pages; Manufacturerrubycon; Websitehttp://www.rubycon.co.jp/cn/; Environmental Compliance

Download Datasheet Parametric View All

10ZLG470MFA8X11.5 Overview

CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 10V, 470uF, THROUGH HOLE MOUNT, RADIAL LEADED, ROHS COMPLIANT

10ZLG470MFA8X11.5 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	rubycon
package instruction	,
Reach Compliance Code	compli
ECCN code	EAR99
capacitance	470 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
diameter	8 mm
dielectric materials	ALUMINUM (WET)
JESD-609 code	e3
leakage current	0.141 mA
length	11.5 mm
Manufacturer's serial number	ZLG
Installation features	THROUGH HOLE MOUNT
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
Package shape	CYLINDRICAL PACKAGE
Package form	Radial
method of packing	Bulk
polarity	POLARIZED
positive tolerance	20%
Rated (DC) voltage (URdc)	10 V
ripple current	550 mA
series	ZLG
surface mount	NO
Delta tangent	0.19
Terminal surface	Tin (Sn)
Terminal pitch	5 mm
Terminal shape	WIRE

Preview

Download Datasheet

View All

MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS

ZLG

SERIES

Load Life: 105

C 1000∼ 5000hours. Ultra Low impedance.

FEATURES

•

Extremely reduced impedance at high frequency range than ZL series.

•

Load Life : 105

C 1000

∼

5000hours.

•

RoHS compliance.

SPECIFICATIONS

Items

Category Temperature Range

Characteristics

-40

∼

+105

6.3∼35V.DC

0.03CV or 3

A whichever is greater.

Rated Voltage Range

Capacitance Tolerance

20%(20

C,120Hz)

(After 2 minutes)

Leakage Current(MAX)

Leakage Current

(µA)

Rated Capacitance

(µF)

Rated Voltage

(V)

Dissipation Factor(MAX)

(tan

)

Rated Voltage

6.3 10 16 25 35

(V)

tanδ

0.22 0.19 0.16 0.14 0.12

(20

C,120Hz)

When nominal capacitance is over 1000

F, tanδ shall be added 0.02 to the listed value with increase of every 1000

After life test with rated ripple current at conditions stated in the table below, the capacitors shall meet the following requirements.

Case Size

Ｌ

6.3

12.5

Life Time

(hrs)

1000

2000

3000

4000

5000

Endurance

Capacitance Change

Dissipation Factor

Leakage Current

Rated Voltage

(V)

Z(-25

C)/Z(20

Z(-40

C)/Z(20

Within ±25% of the initial value.

Not more than 200% of the specified value.

Not more than the specified value.

Low Temperature Stability

Impedance Ratio(MAX)

6.3

(120Hz)

MULTIPLIER FOR RIPPLE CURRENT

Frequency coefficient

Frequency

DIMENSIONS

SLEEVE

(mm)

F ±0.5

(Hz)

4.7∼ 10µF

22∼ 33µF

47∼ 270µF

120

0.24

0.42

0.50

0.55

0.60

0.70

0.53

0.70

0.73

0.77

0.80

0.85

10k

0.80

0.90

0.92

0.94

0.96

0.98

100k <

1.00

L+

MAX

15MIN

4MIN

D+0.5MAX

Coefficient

0.45

1.5

2.0

1.0

2.5

6.3

0.5

2.0

6.3

0.6

12.5

330∼ 680µF

820∼ 1500µF

2200∼ 3900µF

2.5

3.5

5.0

16 :

1.5 L

20 :

2.0

PART NUMBER

ZLG

Rated Voltage

Series

Rated Capacitance

Capacitance Tolerance

Option

Lead Forming

Case Size
