Z86C2116PSCRXXX

Description
Microcontroller, 8-Bit, MROM, Z8 CPU, 16MHz, CMOS, PDIP40, PLASTIC, DIP-40
CategoryThe embedded processor and controller    Microcontrollers and processors
File Size749KB，32 Pages
ManufacturerZilog, Inc.
Websitehttps://www.zilog.com/
Download Datasheet Parametric Compare View All

Z86C2116PSCRXXX Overview

Microcontroller, 8-Bit, MROM, Z8 CPU, 16MHz, CMOS, PDIP40, PLASTIC, DIP-40

Z86C2116PSCRXXX Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerZilog, Inc.
Parts packaging codeDIP
package instructionPLASTIC, DIP-40
Contacts40
Reach Compliance Codeunknow
Has ADCNO
Address bus width16
bit size8
CPU seriesZ8
maximum clock frequency16 MHz
DAC channelNO
DMA channelNO
External data bus width8
JESD-30 codeR-PDIP-T40
JESD-609 codee0
Number of I/O lines32
Number of terminals40
Maximum operating temperature70 °C
Minimum operating temperature
PWM channelNO
Package body materialPLASTIC/EPOXY
encapsulated codeDIP
Encapsulate equivalent codeDIP40,.6
Package shapeRECTANGULAR
Package formIN-LINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
power supply5 V
Certification statusNot Qualified
RAM (bytes)236
rom(word)8192
ROM programmabilityMROM
speed16 MHz
Maximum slew rate50 mA
Maximum supply voltage5.5 V
Minimum supply voltage4.5 V
Nominal supply voltage5 V
surface mountNO
technologyCMOS
Temperature levelCOMMERCIAL
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formTHROUGH-HOLE
Terminal pitch2.54 mm
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
uPs/uCs/peripheral integrated circuit typeMICROCONTROLLER
