MBR60040CTL: DescriptionRectifier Diode, Schottky, 1 Phase, 2 Element, 300A, 40V V(RRM), Silicon,; CategoryDiscrete semiconductor diode; File Size790KB，2 Pages; ManufacturerDaco Semiconductor Co., Ltd.

Download Datasheet Parametric Compare View All

MBR60040CTL Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	MBR60040CTL	-	-	View	Buy Now

MBR60040CTL Overview

Rectifier Diode, Schottky, 1 Phase, 2 Element, 300A, 40V V(RRM), Silicon,

MBR60040CTL Parametric

Parameter Name	Attribute value
Maker	Daco Semiconductor Co., Ltd.
package instruction	R-XUFM-X2
Reach Compliance Code	unknow
ECCN code	EAR99
application	GENERAL PURPOSE
Shell connection	CATHODE
Configuration	COMMON CATHODE, 2 ELEMENTS
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	0.6 V
JESD-30 code	R-XUFM-X2
Maximum non-repetitive peak forward current	4000 A
Number of components	2
Phase	1
Number of terminals	2
Maximum operating temperature	100 °C
Minimum operating temperature	-40 °C
Maximum output current	300 A
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Maximum repetitive peak reverse voltage	40 V
Maximum reverse current	5000 µA
surface mount	NO
technology	SCHOTTKY
Terminal form	UNSPECIFIED
Terminal location	UPPER

Preview

Download Datasheet

View All

DACO SEMICONDUCTOR CO., LTD.

Features

MBR60040CT(R)L

LOW VF SCHOTTKY DIODE MODULE TYPE 600A

High Surge Capability

600Amp Recti er

40Volts

TWIN TOWER

Maximum Ratings

Operating Temperature: -40 C to+100

Sto rage Temperatur: -40 C to +150

Part Number

MBR60040CT(R)L

Maximum

Recurrent

Peak Reverse RMS Voltage

Voltage

40V

28V

Maximum DC

Blocking

Voltage

40V

Electrical Characteristics

Average Forward

Current

(Per pkg)

Peak Forward Surge

Current

(Per leg)

Maximum

Instantaneous

(Per leg)

Forward Voltage

LUG

Teminal

Anode 1

LUG

Teminal

Anode 2

LUG

Teminal

Cathode 1 Cathode 2

Unless Otherwise Specified

600A

4000A

0.60V

5mA

350mA

F(AV)

FSM

TC =100

8.3ms , half sine

I FM

=300A; T

=25

DIM

Baseplate

Common Cathode

Baseplate

R=Common Anode

Inches

Min

Max

3.630

0.800

0.650

0.141

0.490

BSC

1/4-20 UNC FULL

0.275

3.150

0.600

0.312

0.180

0.290

BSC

-----

0.370

0.195

6.99

80.01

15.24

7.92

4.57

Min

-----

17.78

-----

3.30

12.25

34.75

Millimeters

Max

92.40

20.32

16.51

3.60

12.45

BSC

Maximum

Instantaneous

Reverse Current At

Rated DC Blocking

Voltage

(Per leg)

Maximum Thermal

Resistance Junction

To Case

(Per leg)

TJ = 25

TJ = 100

-----

0.700

-----

0.130

0.482

1.368

R jc

0.28

7.37

BSC

-----

9.40

4.95

NOTE :

(1)

Pulse Test: Pulse Width 300

μsec.

Duty Cycle

www.dacosemi.com.tw

-1-
