WDM-15-S-B-9: DescriptionWavelength Division Mux/Demux, 1310nm Min, 1550nm Max; CategoryWireless rf/communication Optical fiber; File Size225KB，1 Pages; ManufacturerLightel Technologies Inc.

Download Datasheet Parametric View All

WDM-15-S-B-9 Overview

Wavelength Division Mux/Demux, 1310nm Min, 1550nm Max

WDM-15-S-B-9 Parametric

Parameter Name	Attribute value
Maker	Lightel Technologies Inc.
Reach Compliance Code	unknow
Fiber optic equipment types	WAVELENGTH DIVISION MUX/DEMUX
Fiber type	SMF-28
Maximum insertion loss	0.8 dB
Minimum isolation	15 dB
Maximum operating temperature	65 °C
Minimum operating temperature
Maximum operating wavelength	1550 nm
Minimum operating wavelength	1310 nm
Nominal operating wavelength	1430 nm
minimum return loss	50 dB

Preview

Download Datasheet

View All

WDM

1310/1550nm FWDM

Parameter

Specification

1260-1360 nm or 1460-1620 nm

1460-1620 nm or 1260-1360 nm

≤ 0.8 dB

≤ 0.6 dB

≥ 45 dB

≥ 15 dB

≥ 50 dB

≥ 55 dB

≤ 0.1 dB

≤ 0.1 ps

300 mW

0° C ~ + 65° C

- 40° C ~ + 85° C

5.5 mm () x 35 mm (L)

5.5 mm () x 40 mm (L)

100.0 mm x 12.0 mm x 8.0 mm

Operating Wavelength Range (Pass

Band)

Operating Wavelength Range (Reflect

Band)

Insertion Loss (Pass Band)

Insertion Loss (Reflect Band)

Isolation (Pass Band)

Isolation (Reflect Band)

Return Loss

Directivity

PDL

PMD

Maximum Power Handling

Operating Temperature

Storage Temperature

Package Dimension

Bare Fiber (B)

900 μm loose tube (L)

Heavy Duty (K, R)

Note 1: All values specified are without connectors.

Note2: Higher performance specifications are available upon request.

Note3: Fiber Type – Corning SMF-28e.

W D

M

-

Wavelength

Fiber Length

13: 1310 nm reflection A: 1 meter

15: 1550 nm reflection B: 1.5 meter

S: Special

-

Connector

0: None

1: FC/PC

2: FC/APC

3: SC/ PC

4: SC/APC

5: FC/SPC

6: SC/SPC

7: LC/UPC

8: LC/SPC

9: Special

A: FC/UPC

B: SC/UPC

C: ST

Pigtail Style

(=Package style)

B: bare fiber

L: 900 μm loose tube

K: 2 mm cable

R: 3 mm cable

www.lightel.com

2210 Lind Ave SW, Suite 100

Renton, WA 98057 USA

(425) 277-8000 ph.

(425) 277-5280 Fax
