Power Inductors - Unshielded
ctparts.com
CTDO5022HC Series
From 0.78 µH to 15 µH
Part
Number
CTDO5022P_-781HC
CTDO5022P_-152HC
CTDO5022P_-222HC
CTDO5022P_-332HC
CTDO5022P_-392HC
CTDO5022P_-472HC
CTDO5022P_-602HC
CTDO5022P_-782HC
CTDO5022P_-103HC
CTDO5022P_-153HC
Not shown at actual size.
SPECIFICATIONS
Parts are available in ±20% tolerance only.
CTDO5022PF
Please specify “F” for RoHS Compliant
Inductance
(µH)
0.78
1.5
2.2
3.3
3.9
4.7
6.0
7.8
10
15
L Test
Freq.
(kHz)
100
100
100
100
100
100
100
100
100
100
DCR
Max.
Ω
(mΩ)
2.6
4.0
6.1
8.6
10
14
17
18
26
32
SRF
Typ.
(MHz)
156
100
75
60
55
40
35
35
28
20
Isat
Typ.
(A)
30
25
20
17
15
13
12
11
10
8.0
Irms
(A)
15
15
12
10
9.0
8.4
7.5
7.5
6.0
4.4
Compliant
Available
RoHS
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
16.26
0.64
B
Typ.
12.7
0.5
C
Max.
8
0.32
D
Max.
22.35
0.88
Parts will be marked with
Significant Digit Dots OR Inductance Code
CHARACTERISTICS
Description:
SMD (high current) power inductor
Applications:
DC/DC converters, computers, LCD displays,
telecommunication equipment and PDA palm tops.
Operating Temperature:
-40°C to +85°C
∆
T:
40°C typically at Irms.
Inductance Tolerance:
±20%
Inductance Drop:
10% typically at Isat.
Testing:
Inductance is tested on an HP4285A at 100 kHz.
Packaging:
Tape & Reel.
Marking:
Color dots OR Inductance code.
Miscellaneous:
RoHS Compliant available.
Additional Information:
Additional electrical & physical
information available upon request.
Samples available. See website for ordering information.
1st significant digit
A
Ind. Code
XXX
2nd significant digit
3rd significant digit
B
C
PAD LAYOUT
D
01.14.05
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2005 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
