Power Inductors - Shielded
ctparts.com
CTDT3316 Series
From 1.0 µH to 1,000 µH
Part
Number
Not shown at actual size.
SPECIFICATIONS
Parts are available in ±20% tolerance only.
CTDT3316PF
Please specify “F” for RoHS Compliant
SPECIFICATIONS
SPECIFICATIONS
0 ADC
Inductance
(µH±20%)
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
680
1000
DCR
Max.
Ω
(Ω)
.025
.030
.035
.040
.045
.050
.055
.060
.084
.090
.110
.150
.290
.360
.390
.730
.880
1.15
1.45
SRF Inductance L Test
Typ.
Rating
Freq.
(MHz)
(µH)
(kHz)
60
55
55
50
45
40
35
25
22
18
16
12
9
8
6
5
4
3
2.5
.50
.70
1.0
1.5
2.0
4.0
5.0
6.0
10
12
27
40
50
80
90
150
200
300
420
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
Max.
Current Energy
Rating Storage
(A)
(µJoules)
5.0
5.0
5.0
5.0
3.0
2.5
2.0
1.8
1.5
1.3
1.0
.90
.80
.60
.50
.40
.35
.30
.25
9.0
12
15
16
10
14
11
12
11
13
13
17
15
15
10
13
13
13
13
Max.
Switch
Freq.
1
1
1
1
1
1
1
1
1
1
1
1
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
CTDT3316P_-102
CTDT3316P_-152
CTDT3316P_-222
CTDT3316P_-332
CTDT3316P_-472
CTDT3316P_-682
CTDT3316P_-103
CTDT3316P_-153
CTDT3316P_-223
CTDT3316P_-333
CTDT3316P_-473
CTDT3316P_-683
CTDT3316P_-104
CTDT3316P_-154
CTDT3316P_-224
CTDT3316P_-334
CTDT3316P_-474
CTDT3316P_-684
CTDT3316P_-105
Compliant
Available
RoHS
1 MHz
500 kHz
500 kHz
500 kHz
500 kHz
500 kHz
500 kHz
PHYSICAL DIMENSIONS
CHARACTERISTICS
Description:
SMD (shielded) power inductor
Applications:
Ideal for high performance DC/DC converter
applications, computers, LCD displays and telecommunication
equipment. Especially those requiring shielding
Operating Temperature:
-40°C to +85°C
Inductance Tolerance:
±20%
Testing:
Inductance is tested on an HP4285A at 100 kHz
Packaging:
Tape & Reel
Marking:
Color dots OR Suffix Code
Miscellaneous:
RoHS Compliant available.
Magnetically shielded
Additional Information:
Higher current parts available. Additional
electrical & physical information available upon request
Samples available. See website for ordering information.
Size
mm
inches
A
Max.
12.95
0.51
B
Max.
9.4
0.37
C
Max.
5.08
0.2
D
2.54
0.1
E
2.54
0.1
F
7.62
0.3
Parts will be marked with
Significant Digit Dots or Suffix Code
A
1st significant digit
B
Suffix code
XXX
2nd significant digit
3rd significant digit
PAD LAYOUT
C
D
E
F
11.17.05
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
