Datasheet> All Categories > Passive components> inductor> CTGS54F-101K

Preview

CTGS54F-101K: Description1 ELEMENT, 100 uH, GENERAL PURPOSE INDUCTOR, SMD; CategoryPassive components inductor; File Size185KB，1 Pages; ManufacturerCT [ Central Technologies ]; Environmental Compliance

Download Datasheet Parametric View All

CTGS54F-101K Overview

1 ELEMENT, 100 uH, GENERAL PURPOSE INDUCTOR, SMD

CTGS54F-101K Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	CT [ Central Technologies ]
Reach Compliance Code	compli
ECCN code	EAR99
DC Resistance	0.7 Ω
Nominal inductance(L)	100 µH
Inductor Applications	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e3
Number of functions	1
Number of terminals	2
Maximum operating temperature	100 °C
Minimum operating temperature	-40 °C
Maximum rated current	0.52 A
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal surface	Matte Tin (Sn)
Terminal location	DUAL ENDED
Terminal shape	ONE SURFACE
Test frequency	0.001 MHz
Tolerance	10%

Preview

Download Datasheet

View All

Power Inductors - Unshielded

ctparts.com

CTGS54 Series

From 1.0 µH to 220 µH

ENGINEERING KIT #7

Not shown at actual size.

Part

Number

CTGS54_-1R0M

CTGS54_-1R2M

CTGS54_-1R5M

CTGS54_-1R8M

CTGS54_-2R2M

CTGS54_-2R7M

CTGS54_-3R3M

CTGS54_-3R9M

CTGS54_-4R7M

CTGS54_-5R6M

CTGS54_-6R8M

CTGS54_-8R2M

CTGS54_-100M

CTGS54_-120M

CTGS54_-150M

CTGS54_-180M

CTGS54_-220M

CTGS54_-270M

CTGS54_-330L

CTGS54_-390L

CTGS54_-470L

CTGS54_-560K

CTGS54_-680K

CTGS54_-820K

CTGS54_-101K

CTGS54_-121K

CTGS54_-151K

CTGS54_-181K

CTGS54_-221K

SPECIFICATIONS

Part numbers indicate tolerance available.

K = ±10%, L = ±15%, M = ±20%

CTGS54F

Please specify “F” for RoHS Compliant

Inductance

(µH)

1.0

1.2

1.5

1.8

2.2

2.7

3.3

3.9

4.7

5.6

6.8

8.2

10

12

15

18

22

27

33

39

47

56

68

82

100

120

150

180

220

L Test

Freq.

(_Hz)

7.96M

2.52M

1.0k

DCR

Max.

Ω

(Ω)

.015

.020

.025

.030

.035

.040

.045

.050

.060

.070

.080

.090

.10

.12

.14

.15

.18

.20

.23

.32

.37

.42

.46

.60

.70

.93

1.1

1.4

1.6

Rated

DC

(A)

5.9

5.2

4.7

4.0

3.8

3.4

3.3

2.9

2.8

2.4

2.1

2.0

1.4

1.3

1.2

1.1

.97

.88

.80

.72

.68

.61

.58

.52

.48

.40

.38

.35

Compliant

Available

RoHS

CHARACTERISTICS

Description:

SMD power inductor

Applications:

VTR power supplies, OA equipment, LCD

televisions, PC notebooks, portable communication equipment,

DC/DC converters

Operating Temperature:

-30°C to +100°C

Inductance Tolerance:

±10%, ±15%, ±20%

Testing:

Inductance is tested on an HP4284A or HP4285A at

specified frequency

Packaging:

Tape & Reel

Marking:

Marked with inductance code

Rated DC:

The value of current when the inductance is 10%

lower than its initial value at 0 Adc or D.C. current when at

ΔT

= 40°C whichever is lower

Miscellaneous:

RoHS Compliant available

Additional Information:

Additional electrical & physical

information available upon request

Samples available. See website for ordering information.

PHYSICAL DIMENSIONS

Size

mm

inches

A

5.8±0.3

0.23±0.012

B

5.2±0.3

0.21±0.012

C

4.5±0.4

0.18±0.016

D

Typ.

1.3

0.051

B

C

D

XXX

10.19.05

A

Marking

PAD LAYOUT

Technologies

Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids

800-684-5322

Inside US

949-453-1811

Outside US

CT Magnetics reserves the right to make improvements or change specifications without notice

CENTRAL
