Power Inductors - Shielded
ctparts.com
CTIHLP72F Series
From .22 µH to 4.7 µH
Not shown at actual size.
SPECIFICATIONS
Parts are only available ±20% inductance tolerance only
*Irms will cause the coil temp. rise approximately
ΔT=40°C
without core loss.
**Isat will cause L0 to drop approximately 20% typ.
L Test
Freq.
(KHz)
100
100
100
100
100
100
100
100
100
*Irms
Typ.
(A)
14
12
11
9
7
4
5
3.25
3
**Isat
Typ.
(A)
26
18
18
17
14
12
9
7
5
DCR
Max.
Ω
(mΩ)
5.7
7.0
9.3
13.9
18
34
46
60
78
Part
Number
CTIHLP72F-R22M
CTIHLP72F-R33M
CTIHLP72F-R47M
CTIHLP72F-R68M
CTIHLP72F-1R0M
CTIHLP72F-1R5M
CTIHLP72F-2R2M
CTIHLP72F-3R3M
CTIHLP72F-4R7M
Inductance
(µH)
.22
.33
.47
.68
1.0
1.5
2.2
3.3
4.7
Compliant
RoHS
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
7.8
0.31
6.86±0.5
0.27±0.02
B
C
Max.
7.0
0.28
D
6.47±0.5
0.25±0.02
E
Max.
2.0
0.079
F
Max.
1.8
0.071
G
1.6±0.5
H
2.1±0.5
0.063±0.02 0.083±0.02
D
H
G
CHARACTERISTICS
Description:
SMD (shielded) power inductor
Applications:
PDA, Notebook, Desktop, Server applications. High
current POL converters. Low profile, high current power supplies.
Battery powered devices. DC/DC converters in distributed power
systems. DC/DC converter for Field Programmable Gate Array
(FPGA).
Operating Temperature:
-55°C to +125°C
Storage Temperature:
-55°C to +125°C
Inductance Tolerance:
±20%
Testing:
Inductance is tested on an HP4285A at 100KHz, 0.25V
Packaging:
Tape & Reel
Marking:
Parts are marked with inductance code
Miscellaneous:
RoHS Compliant.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
08.01.07
XXX
C
B
A
F
E
Marking: Inductance Code
RECOMMENDED LAND PATTERN
7.4 Typ.
3.4
Typ.
3.7
Typ.
Technologies
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2007 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
