AP105A332JQX2A datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> capacitor> AP105A332JQX2A

AP105A332JQX2A: DescriptionCeramic Capacitor, Multilayer, Ceramic, 50V, 5% +Tol, 5% -Tol, C0G, 30ppm/Cel TC, 0.0033uF, Surface Mount, 1210, CHIP; CategoryPassive components capacitor; File Size156KB，3 Pages; ManufacturerAVX; Related ProductsFound19parts with similar functions to AP105A332JQX2A

Download Datasheet Parametric View All

AP105A332JQX2A Overview

Ceramic Capacitor, Multilayer, Ceramic, 50V, 5% +Tol, 5% -Tol, C0G, 30ppm/Cel TC, 0.0033uF, Surface Mount, 1210, CHIP

AP105A332JQX2A Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	AVX
package instruction	CHIP
Reach Compliance Code	_compli
ECCN code	EAR99
capacitance	0.0033 µF
Capacitor type	CERAMIC CAPACITOR
dielectric materials	CERAMIC
high	0.94 mm
JESD-609 code	e0
length	3.2 mm
Manufacturer's serial number	APS
Installation features	SURFACE MOUNT
multi-layer	Yes
negative tolerance	5%
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package shape	RECTANGULAR PACKAGE
Package form	SMT
method of packing	TR, PAPER, 7 INCH
positive tolerance	5%
Rated (DC) voltage (URdc)	50 V
series	AP10(3/5,NP0)
size code	1210
surface mount	YES
Temperature characteristic code	C0G
Temperature Coefficient	-/+30ppm/Cel ppm/°C
Terminal surface	Tin/Lead (Sn/Pb)
Terminal shape	WRAPAROUND
width	2.5 mm
Base Number Matches	1

Preview

Download Datasheet

View All

APS Series

APS for COTS+ Applications

GENERAL DESCRIPTION

As part of our continuing support to high reliability customers, AVX

has launched an Automotive Plus Series of parts (APS) qualified and manufactured

in accordance with automotive AEC-Q200 standard. Each production batch is

quality tested to an enhanced requirement and shipped with a certificate of confor-

mance. On a quarterly basis a reliability package is issued to all APS customers.

A detailed qualification package is available on request and contains results on a

range of part numbers including:

• X7R dielectric components containing BME electrode and copper terminations

with a Ni/Sn plated overcoat.

• X7R dielectric components BME electrode and soft terminations with a Ni/Sn

plated overcoat (FLEXITERM™).

• X7R for Hybrid applications.

• NP0 dielectric components containing Pd/Ag electrode and silver termination

with a Ni/Sn plated overcoat.

We are also able to support customers who require an AEC-Q200 grade compo-

nent finished with Tin/Lead.

HOW TO ORDER

AP03

Size

AP03=0603

AP05=0805

AP06=1206

AP10=1210

AP12=1812

Voltage

16V = Y

25V = 3

50V = 5

100V = 1

200V = 2

500V = 7

Dielectric

NP0 = A

X7R = C

104

Capacitance

Code (In pF)

2 Significant Digits +

Number of Zeros

e.g. 10µF = 106

Capacitance

Tolerance

J = ±5%

K = ±10%

M = ±20%

Special Code

A = Std. Product

Failure Rate

Packaging

Terminations

Q = APS

T = Plated Ni and Sn** 2 = 7" Reel

4 = 13" Reel

Z = FLEXITERM

U = Conductive Epoxy**

B = 5% min lead

X = FLEXITERM

with

5% min lead

**RoHS compliant

NOTE: Contact factory for availability of Termination and Tolerance Options for Specific Part Numbers.
