Crimp
ZM
CONNECTOR
• Compact design
1.5mm
(.059") pitch
Crimp style Wire-to-wire connectors Matable with ZH and ZR receptacles
Features ––––––––––––––––––––––––
Precision stamping technology is applied to produce mate pins
that are only 0.5mm (.020") in diameter. This results in ultra-
compact wire-to-wire connectors that are a mere 3.6mm (.142")
thick. When used with ZH crimp style connectors, high density
mounting with a total connector length of only 9.2mm (.362") is
possible.
• Housing-to-terminal locks
Spring action housing-to-terminal locks are an inherent part of
the housing, and assure smooth contact insertion and firm
contact retention.
• Both crimp style and insulation displacement
receptacles can be used
1.5mm (.059") pitch connectors allow higher
densities.
Both ZH crimp style and ZR insulation displacement connector
receptacles can be accommodated by the ZM connector.
Thus, mounting designs can be matched to current "Z" series
connector use.
• Fully shrouded header resists "rocking"
during mating
This fully shrouded header provides protection from rocking the
connector halves back and forth during mating and unmating.
Specifications –––––––––––––––––––
• Current rating: 0.7A AC, DC max. (AWG #28)
• Voltage rating: 50V AC, DC max. (See Note below.)
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/20m
Ω
max.
After environmental testing/30m
Ω
max.
• Insulation resistance:
500M
Ω
min.
• Withstanding voltage: 500V AC/minute
• Applicable wire: AWG #30 to #28
Note: Contacts are exposed at the housing lances.
Care should be taken so that these parts do not touch the
metal section of the chasis.
* Contact JST for details.
JS
Crimp style
ZH connector
ST
3
JS
T
Insulation displacement
ZR connector
606
3
T
2
1
ZM connector
Standards–––––––––––––––––––––––
0
1
Recognized E60389
Certified LR20812
ZM
CONNECTOR
Plug / ZM connector –––––––––––––––––––––––––––––––––––––––––––––––––––––––
Contact
1.05
(.041)
Housing
B
3.6(.142)
7.0(.276)
2.8(.110)
0.5
(.020)dia.
2.2(.087)
1.0(.039)
3
2
1
1.5
(.059) 1.5
(.059)
A
2.8
(.110)
Applicable wire
Model No.
SMM-003T-P0.5
mm
2
0.05 to 0.08
AWG #
30 to 28
Insulation O.D.
mm(in.)
0.7 to 0.9(.028 to .035)
Q´ty /
reel
16,000
Circuits
2
3
9
13
Model No.
ZMR- 2
ZMR- 3
ZMR- 9
ZMR-13
Dimensions mm(in.)
A
1.5(.059)
3.0(.118)
12.0(.472)
18.0(.709)
0.3
(.012)
4.1(.161)
8.1(.319)
B
5.5(.217)
7.0(.276)
16.0(.630)
22.0(.866)
Q´ty /
bag
1,000
1,000
1,000
1,000
Material and Finish
Phosphor bronze, tin-plated
Material
Glass-filled nylon 66, UL94V-0
Receptacle / ZH connector (Crimp style) ––––––––––––––––––––––––––––––––––––––
Contact
Housing
B
A
1.5(.059)
1.2
(.047)
4.0(.157)
1.0
(.039)
1.5(.059)
1.4
(.055)
1.1
(.043)
3.4(.134)
1.5
(.059)
0.3
(.012)
Dimensions mm(in.)
Model No.
SZH-003T-P0.5
mm
2
0.032 to 0.08
AWG #
32 to 28
Insulation
mm(in.)
Q´ty /
reel
Circuits
2
3
9
13
Model No.
ZHR- 2
ZHR- 3
ZHR- 9
ZHR-13
Dimensions mm(in.)
A
1.5(.059)
3.0(.118)
12.0(.472)
18.0(.709)
0.3
(.012)
4.2(.165)
0.3(.012)
0.5 to 0.9(.020 to .035) 16,000
Material and Finish
Phosphor bronze, tin-plated
Nylon 66, UL94V-0
9
2
1
B
4.5(.117)
6.0(.236)
15.0(.591)
21.0(.827)
Q´ty /
bag
1,000
1,000
1,000
1,000
Material
607
ZM
CONNECTOR
Receptacle / ZR connector (IDC) ––––––––––––––––––––––––––––––––––––––––––––
Receptacle
Circuits
2
A
1.5
(.059)
1.5
(.059)
4.4(.173)
Model No.
AWG #30
02ZR-3H
03ZR-3H
09ZR-3H
13ZR-3H
AWG #28
02ZR-8M
03ZR-8M
09ZR-8M
13ZR-8M
Dimensions mm(in.)
A
1.5(.059)
3.0(.118)
12.0(.472)
18.0(.709)
B
4.5(.117)
6.0(.236)
15.0(.591)
21.0(.827)
Q´ty /
bag
2,000
2,000
2,000
2,000
3
9
13
3.1(.122)
2.7(.106)
Material
Contact: Phosphor bronze, tin-plated
Housing: Glass-filled nylon 66, UL94V-0
JST
B
4.1(.161)
Assembly layout ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
ZM/ZH connector
ZM/ZR connector
9.2(.362)
9.1(.358)
Applicator for the semi-automatic press AP-K2N –––––––––––––––––––––––––––––––
Contact
SMM-003T-0.5
Crimp applicator MKS-L
with safety cover
without safety cover
APLMK SMM003-05
APLNC SMM003-05
3.6(.142)
Compact Crimp applicator MKS-LS
with safety cover
without safety cover
APLMKLS SMM003-05
APLLSNC SMM003-05
Strip-crimp applicator MKS-SC
with safety cover
APLSC SMM003-05
608
3.6(.142)
