880151-3

Description
HEADER CONNECTOR,PCB MNT,RECEPT,3 CONTACTS,PIN,0.1 PITCH,R ANGLE PC TAIL TERMINAL,BLACK
CategoryThe connector    The connector
File Size116KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric View All

880151-3 Overview

HEADER CONNECTOR,PCB MNT,RECEPT,3 CONTACTS,PIN,0.1 PITCH,R ANGLE PC TAIL TERMINAL,BLACK

880151-3 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerTE Connectivity
Reach Compliance Codecompli
ECCN codeEAR99
Other featuresW/O STANDOFF & MOUNTING EARS
body width0.098 inch
body length0.3 inch
Body/casing typeRECEPTACLE
Connector typeBOARD CONNECTOR
Contact to complete cooperationSN ON NI
Contact completed and terminatedTIN OVER NICKEL
Contact point genderMALE
Contact materialBRASS
contact modeRECTANGULAR
Contact styleSQ PIN-SKT
Dielectric withstand voltage750VAC V
Insulation resistance5000000000 Ω
Insulator colorBLACK
insulator materialGLASS FILLED THERMOPLASTIC
Manufacturer's serial number880151
Plug contact pitch0.1 inch
Installation methodRIGHT ANGLE
Installation typeBOARD
Number of connectorsONE
PCB row number1
Number of rows loaded1
Maximum operating temperature105 °C
Minimum operating temperature-65 °C
PCB contact patternRECTANGULAR
Plating thickness100u inch
Rated current (signal)3 A
GuidelineUL, CSA
reliabilityCOMMERCIAL
Terminal length0.114 inch
Terminal pitch2.54 mm
Termination typeSOLDER
Total number of contacts3
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
PC B C onnectors
>
Product Feature Selector
> Product Details
880151-3 Product Details
Live Product Chat
Product Photo
.100 inch AMPMODU Headers
C onve rte d to EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
880151-3
T E I nternal N umber: 8 8 0 1 5 1 - 3
Product Highlights:
l
Header
l
Header Type = Breakaway
l
Number of Rows = Single
l
Number of Positions = 3
l
Mating Post Length = 6.10 mm
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Header
l
Number of Positions
= 3
l
Mount Angle
= Right Angle
l
PC B Retention Feature
= No
l
Surface Mount C ompatible
= No
l
Board Standoff
= Without
l
Mounting Ears
= Without
l
Mating C onnector Lock
= Without
l
Post Size (mm [in]) = 0.64 [.025]
l
C omment = Headers may be broken to desired number of positions
using Hand Tool No. 91406-1, or Tool Kit No. 314818-1. Other tail
lengths are available, consult Tyco Electronics.
Mechanical Attachment:
l
Mating Post Length (mm [in]) = 6.10 [0.240]
l
Panel Attachment
= Without
Termination Related Features:
l
Termination Post Length (mm [in])
= 2.90 [0.114]
l
Solder Tail C ontact Plating = Tin-Lead over Nickel
Body Related Features:
l
Header Type
= Breakaway
l
Number of Rows
= Single
l
C enterline, Matrix (mm [in])
= 2.54 [.100]
l
Selectively Loaded
= No
l
Mount Type
= Printed C ircuit Board
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold (15)
l
C ontact Shape = Square
l
C ontact Base Material = Brass
Housing Related Features:
l
Housing Material = Thermoplastic
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
l
RoHS/ELV C ompliance History = C onverted to comply with RoHS
directive
Conditions for Usage:
l
High Temperature Housing
= No
Operation/Application:
l
High Speed Serial Data C onnector
= No
Other:
l
Brand = AMP
