0805 CHIP INDUCTORS
Military Grade Chip Inductors
ML336RAE
Ceramic body and wire wound construction provide highest
SRFs available in 0805 size. These ultra-compact inductors
provide excellent Q values, even at high frequencies.
Inductance
2
(nH)
3.3 @ 250 MHz
6.8 @ 250 MHz
8.2 @ 250 MHz
10 @ 250 MHz
12 @ 250 MHz
15 @ 250 MHz
18 @ 250 MHz
22 @ 250 MHz
27 @ 250 MHz
33 @ 250 MHz
39 @ 250 MHz
47 @ 200 MHz
56 @ 200 MHz
68 @ 200 MHz
82 @ 150 MHz
100 @ 150 MHz
120 @ 150 MHz
150 @ 100 MHz
180 @ 100 MHz
220 @ 100 MHz
This robust version of Coilcraft’s standard 0805HS series
features high temperature materials that allow operation
in ambient temperatures up to 155°C.
SRF min
4
(MHz)
7900
5500
4700
4200
4000
3400
3300
2600
2500
2050
2000
1650
1550
1450
1300
1200
1100
920
870
850
Part
number
1
Percent
tolerance
5
5
5
5
5
5
5
5,2
5,2
5,2
5,2
5,2
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2
Q
min
3
DCR max
5
(Ohms)
0.08
0.11
0.12
0.10
0.15
0.17
0.20
0.22
0.25
0.27
0.29
0.31
0.34
0.38
0.42
0.46
0.51
0.56
0.64
0.70
Irms
6
(mA)
600
600
600
600
600
600
600
500
500
500
500
500
500
500
400
400
400
400
400
400
Color
code
Black
Brown
Red
Blue
Orange
Yellow
Green
Blue
Violet
Gray
White
Black
Brown
Red
Orange
Yellow
Green
Blue
Violet
Gray
ML336RAE-030JLZ
ML336RAE-060JLZ
ML336RAE-080JLZ
ML336RAE-100JLZ
ML336RAE-120JLZ
ML336RAE-150JLZ
ML336RAE-180JLZ
ML336RAE-220_LZ
ML336RAE-270_LZ
ML336RAE-330_LZ
ML336RAE-390_LZ
ML336RAE-470_LZ
ML336RAE-560_LZ
ML336RAE-680_LZ
ML336RAE-820_LZ
ML336RAE-101_LZ
ML336RAE-121_LZ
ML336RAE-151_LZ
ML336RAE-181_LZ
ML336RAE-221_LZ
50 @ 1500 MHz
50 @ 1000 MHz
50 @ 1000 MHz
60 @ 500 MHz
50 @ 500 MHz
50 @ 500 MHz
50 @ 500 MHz
55 @ 500 MHz
55 @ 500 MHz
60 @ 500 MHz
60 @ 500 MHz
60 @ 500 MHz
60 @ 500 MHz
60 @ 500 MHz
65 @ 500 MHz
65 @ 500 MHz
50 @ 250 MHz
50 @ 250 MHz
50 @ 250 MHz
50 @ 250 MHz
1. When ordering, please specify
tolerance
and
testing
codes:
ML336RAE-221GLZ
Tolerance: F
= 1%
G
= 2%
J
= 5%
Testing: Z
= Coilcraft Critical Products Environmental Stress
Conditions Testing.
H
= Coilcraft Qual + Coilcraft Hi-Rel Burn-in
P
= Coilcraft Qual + MIL-STD-981 Class S Group A
screening
N
= Coilcraft Qual + MIL-STD-981 Class B Group A
screening
C
= Coilcraft Qual + MIL-STD-981 Class S Group A
screening + MIL-STD-981 Class S Group B qualification
W
= Coilcraft Qual + MIL-STD-981 Class B Group A
screening + MIL-STD-981 Class S Group B qualification
Inductance measured using a Coilcraft SMD-A fixture in an Agilent/HP
4286A impedance analyzer with Coilcraft-provided correlation pieces.
Q measured using an Agilent/HP 4291A with an Agilent/HP 16193 test
fixture.
SRF measured using an Agilent/HP 8720D network analyzer and a
Coilcraft SMD-D test fixture.
DCR measured on a Cambridge Technology micro-ohmmeter and a
Coilcraft CCF858 test fixture.
Current that causes a 15°C temperature rise from 25°C ambient.
Electrical specifications at 25°C.
Core material
Ceramic
Terminations
Silver-palladium-platinum-glass frit
Weight:
9.8 – 10.9 mg
Ambient temperature
–55°C to +140°C with
Irms
current, +140°C
to +155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+100 to +250 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
2000 per 7″ reel
Plastic tape: 8 mm wide, 0.23 mm thick, 4 mm pocket spacing,
1.3 mm pocket depth
2.
3.
4.
5.
6.
7.
®
These parts are preproduction products for electrical evaluation only.
Specification subject to change without notice.
Document ML159-1
Revised 06/02/09
