PJ48ADJCZ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> PJ48ADJCZ

PJ48ADJCZ: DescriptionAdjustable Positive LDO Regulator, 0.7V Dropout, PSFM3, TO-220, 3 PIN; CategoryPower/power management The power supply circuit; File Size160KB，3 Pages; ManufacturerPromax-Johnton Electronic Corporation

Download Datasheet Parametric Compare View All

PJ48ADJCZ Overview

Adjustable Positive LDO Regulator, 0.7V Dropout, PSFM3, TO-220, 3 PIN

PJ48ADJCZ Parametric

Parameter Name	Attribute value
Maker	Promax-Johnton Electronic Corporation
Parts packaging code	SFM
package instruction	TO-220, 3 PIN
Contacts	3
Reach Compliance Code	unknow
ECCN code	EAR99
Maximum drop-back voltage 1	0.7 V
JESD-30 code	R-PSFM-T3
Number of functions	1
Number of terminals	3
Working temperatureTJ-Max	125 °C
Operating temperatureTJ-Mi
Maximum output current 1	0.5 A
Package body material	PLASTIC/EPOXY
encapsulated code	TO-220
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Certification status	Not Qualified
Regulator type	ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR
surface mount	NO
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
