DWDM
8 Channel 100 GHz & 200 GHz DWDM Module
Parameter
Center Wavelength (λc)
Channel Pass Band
Insertion Loss (Pass Band)
Uniformity
Pass Band Ripple
Adjacent Channel Isolation
Non-Adjacent Channel Isolation
Directivity
Return Loss
PDL
PMD
Maximum Power
Operating Temperature
Storage Temperature
Package
Dimensions
MD Type packaging
100 GHz
ITU Grid
≥ λc
± 0.11 nm
≤
3.0 dB
≤
1.5 dB
≤
0.5 dB
≥
25 dB
≥
40 dB
≥
50 dB
≥
45 dB
≤
0.20 dB
≤
0.1 ps
300 mW
0° C to + 65° C
200 GHz
≥ λc
± 0.25 nm
≤
2.8 dB
≥
30 dB
≤
0.15 dB
- 40° C ~ + 85° C
110 mm x 90 mm x 7 mm
100 mm x 90 mm x 12 mm
Note1: All values specified are without connectors.
Note2: Higher performance specifications are available upon request.
Note3: Fiber type Corning SMF-28e.
Note4: Channel count is from low to high for mux and high to low for demux if mux & demux are packaged in one cassette. In this
case the first channel & last channel in P/N is for mux.
Note5: Over operating temperature All SOP
D WM-
-
- 0 8 -
Number of
Channels
08: 8 Ch
-
-
-
Connector
0: None
1: FC/PC
2: FC/APC
3: SC/ PC
4: SC/APC
5: FC/SPC
6: SC/SPC
7: LC/UPC
8: LC/SPC
9: Special
A: FC/UPC
B: SC/UPC
C: ST
Channel Spacing Module Type
1: 100 GHz
M: Mux
2: 200 GHz
D: Demux
MD: Mux &
Demux in
One cassette
1
st
ITU Channel# Fiber Length
Pigtail Style
e.g 23: 1558.98 nm A: 1 meter
(=Package style)
B: 1.5 meter B: bare fiber
S: Special
L: 900
µm
loose tube
