SAK-XC164LM-16F20F datasheet, PDF

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> SAK-XC164LM-16F20F

SAK-XC164LM-16F20F: DescriptionMicrocontroller, 16-Bit, FLASH, 20MHz, CMOS, PQFP64, 0.50 MM PITCH, GREEN, PLASTIC, TQFP-64; CategoryThe embedded processor and controller Microcontrollers and processors; File Size1MB，60 Pages; ManufacturerInfineon; Websitehttp://www.infineon.com/

Download Datasheet Parametric View All

SAK-XC164LM-16F20F Overview

Microcontroller, 16-Bit, FLASH, 20MHz, CMOS, PQFP64, 0.50 MM PITCH, GREEN, PLASTIC, TQFP-64

SAK-XC164LM-16F20F Parametric

Parameter Name	Attribute value
Maker	Infineon
Parts packaging code	QFP
package instruction	0.50 MM PITCH, GREEN, PLASTIC, TQFP-64
Contacts	64
Reach Compliance Code	compli
Has ADC	NO
Other features	ALSO REQUIRES 5V SUPPLY
Address bus width
bit size	16
maximum clock frequency	20 MHz
DAC channel	NO
DMA channel	NO
External data bus width
JESD-30 code	S-PQFP-G64
length	10 mm
Number of I/O lines	47
Number of terminals	64
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	LFQFP
Package shape	SQUARE
Package form	FLATPACK, LOW PROFILE, FINE PITCH
Certification status	Not Qualified
ROM programmability	FLASH
Maximum seat height	1.6 mm
speed	20 MHz
Maximum supply voltage	2.7 V
Minimum supply voltage	2.35 V
Nominal supply voltage	2.5 V
surface mount	YES
technology	CMOS
Temperature level	AUTOMOTIVE
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	QUAD
width	10 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER

Preview

Download Datasheet

View All

Data Sheet, V1.1, Aug. 2006

XC164LM

16-Bit Single-Chip Microcontroller

with C166SV2 Core

Microcontrollers

XC164LM

Derivatives

Preliminary

Table of Contents

2.1

3.1

3.2

3.3

3.4

3.5

3.6

3.7

3.8

3.9

3.10

3.11

3.12

3.13

3.14

4.1

4.2

4.3

4.3.1

4.3.2

4.3.3

5.1

5.2

Summary of Features

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

General Device Information

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Pin Configuration and Definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Functional Description

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Memory Subsystem and Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Central Processing Unit (CPU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Interrupt System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

On-Chip Debug Support (OCDS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Capture/Compare Unit (CAPCOM2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

General Purpose Timer (GPT12E) Unit . . . . . . . . . . . . . . . . . . . . . . . . . . .

Real Time Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Asynchronous/Synchronous Serial Interfaces (ASC0/ASC1) . . . . . . . . . .

High Speed Synchronous Serial Channels (SSC0/SSC1) . . . . . . . . . . . .

Watchdog Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Clock Generation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Parallel Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Instruction Set Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Electrical Parameters

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

General Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DC Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

AC Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Definition of Internal Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

On-chip Flash Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

External Clock Drive XTAL1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Package and Reliability

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Flash Memory Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Data Sheet

V1.1, 2006-08
