SURFACE MOUNT ALUMINUM ELECTROLYTIC CAPACITORS
ZC
Height 5.5mmL, Low Impedance
Series
Low Impedance
Solvent Proof
Chip type, low impedance temperature range up to 105 C
Designed for surface mounting on high density PC board
Applicable to automatic insertion machine using carrier tape
Complied to the RoHS directive
Item
Operating temperature range
Leakage current max.
Capacitance tolerance
Dissipation factor max.
(at 120Hz, 20°
C)
Low temperature characteristics
(Impedance ratio at 120Hz)
Load life
(after application of the rated
voltage for 1000 hours at 105°
C)
Shelf life (at 105°
C)
Characteristics
-55 ~ +105 C
I = 0.01CV or 3 A whichever is greater (after 2 minutes)
20% at 120Hz, 20 C
WV
tan
WV
Z-25 C/Z+20 C
Z-55 C/Z+20 C
Leakage current
Capacitance change
tan
6.3
0.22
6.3
2
4
10
0.19
10
2
4
16
0.16
16
2
3
25
0.14
25
2
3
35
0.12
35
3
3
Less than specified value
Within 20% of initial value
Less than 200% of specified value
After 1000 hours no load test, leakage current, capacitance and tan are same as load life value.
The measurement shall be performed at 20 C by the KS C 6503 clause 5.1.
The following specifications shall be satisfied when the capacitors are restored to 20 C
after exposing them at 250 C for 30 seconds.
Less than specified value
Leakage current
Within 10% of initial value
Capacitance change
Less than specified value
tan
Unit : mm
Positive
0.4 max.
Resistance to soldering heat
CHIP TYPES
DRAWING
Capacitance
-Series code of ZC is “Z”
Plastic plateform
Series Code
0.3 max.
C 0.2
Voltage
B 0.2
E 0.2
47
6Z
Lot No.
ØD
4
5
6.3
W
4.8
5.8
7.1
B
4.3
5.3
6.6
C
4.3
5.3
6.6
E
1.0
1.4
2.2
D 0.5
Voltage mark for
6.3V is 6
5.3 0.2
0.5 0.8
DIMENSIONS & MAXIMUM PERMISSIBLE RIPPLE CURRENT
μ
F
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
WV
6.3
10
16
25
4
4
4
4
4
5
5
6.3
6.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
35
5.0
5.0
5.0
5.0
5.0
2.6
2.6
1.3
1.3
50
50
50
50
50
80
80
115
115
W 0.2
Negative
4
5
5
6.3
6.3
5.3
5.3
5.3
5.3
5.3
5.0
2.6
2.6
1.3
1.3
50
80
80
115
115
5
5
6.3
6.3
5.3
5.3
5.3
5.3
2.6
2.6
1.3
1.3
80
80
115
115
4
5
5
6.3
6.3
5.3
5.3
5.3
5.3
5.3
5.0
2.6
2.6
1.3
1.3
50
80
80
115
115
4
4
5
6.3
6.3
6.3
5.3
5.3
5.3
5.3
5.3
5.3
5.0
5.0
2.6
1.3
1.3
1.3
50
50
80
75
115
115
Ripple current (mA rms) at 105 C, 100kHz
Impedance (Ω) at 20 C, 100kHz
Case size D L(mm)
FREQUENCY COEFFICIENT OF PERMISSIBLE RIPPLE CURRENT
Frequency
Coefficient
50Hz
0.35
120Hz
0.5
300Hz
0.64
1kHz
0.83
10kHz≦
1.00
63
