BDP953 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> BDP953

BDP953: DescriptionNPN Silicon AF Power Transistors (For AF drivers and output stages High collector current High current gain); CategoryDiscrete semiconductor The transistor; File Size43KB，4 Pages; ManufacturerSIEMENS; Websitehttp://www.infineon.com/

Download Datasheet Parametric Compare View All

BDP953 Overview

NPN Silicon AF Power Transistors (For AF drivers and output stages High collector current High current gain)

BDP953 Parametric

Parameter Name	Attribute value
Maker	SIEMENS
package instruction	SMALL OUTLINE, R-PDSO-G4
Reach Compliance Code	unknow
Is Samacsys	N
Shell connection	COLLECTOR
Configuration	SINGLE
JESD-30 code	R-PDSO-G4
Number of components	1
Number of terminals	4
Maximum operating temperature	150 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Maximum power consumption environment	3 W
Certification status	Not Qualified
surface mount	YES
Terminal form	GULL WING
Terminal location	DUAL
transistor applications	AMPLIFIER
Transistor component materials	SILICON
Base Number Matches	1

Preview

Download Datasheet

View All

BDP 951

NPN Silicon AF Power Transistors

• For AF drivers and output stages

• High collector current

• High current gain

• Low collector-emitter saturation voltage

• Complementary type: BDP952...BDP956 (PNP)

Type

BDP 951

BDP 953

BDP 955

Marking Ordering Code

BDP 951 Q62702-D1339

BDP 953 Q62702-D1341

PDP 955 Q62702-D1343

Pin Configuration

1=B

2=C

3=E

4=C

Package

SOT-223

Maximum Ratings

Parameter

Collector-emitter voltage

BDP 951

BDP 953

BDP 955

Collector-base voltage

BDP 951

BDP 953

BDP 955

Emitter-base voltage

DC collector current

Peak collector current

Base current

Peak base current

Total power dissipation,

= 99°C

Junction temperature

Storage temperature

Thermal Resistance

Junction ambient

Symbol

Values

100

120

Unit

CEO

CBO

100

120

140

EBO

tot

stg

thJA

thJS

200

500

150

- 65 ... + 150

≤

°C

K/W

Junction - soldering point

1) Package mounted on pcb 40mm x 40mm x 1.5mm / 6cm

Semiconductor Group

Nov-28-1996
