DC COMPONENTS CO., LTD.
R
SR220
THRU
SR2100
RECTIFIER SPECIALISTS
TECHNICAL SPECIFICATIONS OF SCHOTTKY BARRIER RECTIFIER
VOLTAGE RANGE - 20 to 100 Volts
CURRENT - 2.0 Ampere
FEATURES
*
*
*
*
*
*
Low switching noise
Low forward voltage drop
High current capability
High switching capability
High surge capabitity
High reliability
DO-15
MECHANICAL DATA
* Case: Molded plastic
* Epoxy: UL 94V-0 rate flame retardant
* Lead: MIL-STD-202E, Method 208 guaranteed
* Polarity: Color band denotes cathode end
* Mounting position: Any
* Weight: 0.4 gram
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Dimensions in inches and (millimeters)
SYMBOL
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
.375*(9.5mm) lead length
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC Method)
Maximum Instantaneous Forward Voltage at 2.0A DC
Maximum DC Reverse Current
at Rated DC Blocking Voltage
Typical Thermal Resistance (Note 1)
Typical Junction Capacitance (Note 2)
Operating Temperature Range
Storage Temperature Range
@T
A
= 25 C
@T
A
= 100
o
C
o
V
RRM
V
RMS
V
DC
I
O
I
FSM
V
F
I
R
R
θ
JA
C
J
T
J
T
STG
SR220 SR230 SR240 SR250 SR260 SR280 SR2100
20
30
40
50
60
80
100
14
20
21
30
28
40
35
50
2.0
50
.55
1.0
20
50
110
-50 to + 125
-65 to + 150
.70
.85
42
60
56
80
70
100
UNITS
Volts
Volts
Volts
Amps
Amps
Volts
mAmps
mAmps
0
C/ W
pF
0
0
C
C
NOTES : 1. Thermal Resistance (Junction to Ambient): Vertical PC Board Mounting, 0.375"(9.5mm) Lead Length.
2. Measured at 1 MHz and applied reverse voltage of 4.0 volts.
22
