5,08
Technical Data:
Insertion/withdrawel force per contact:
Mechanical operations:
Contact resistance:
Operation Temperature:
Solder temperature:
Suitable assembly process:
RoHS compliance:
17,9
+0,25
11,8
-0,08
≤
10N /
≤
1,6N
≥
500
≤
1 mOhm
-55°C - +125°C
according JEDEC 020C
leadfree wave / reflow soldering
yes (6/6)
right angle male DIN connector
antistatic plastic bag
100 pieces per bag
label or direct printed on bag
required date see ERNI labeling spec. 254792
40A
6
Designed for use with:
Packaging:
Packaging unit:
Marking of packaging:
Current capacity:
6,6
3
3
±0,05
4,8
0,8
2,3
-0,08
9,5
+0,15
+0,1
5,2
6,4
3,6
-0,05
+0,1
Layout
Missing informations
and dimensions
see at DIN 41626
594168
294751
1
1
1,5-2,5µm Cu, 2-3µm NiP+,
0,15µm Au
2-3µm Ni
min. 1,3µm Au
Plating
Mating Area
2-3µm Ni
0,4µm Au max.
Plating
Termination Area
5,08
M 2:1
Part-No.
Copyright by ERNI GmbH
Proprietary notice pursuant to ISO 16016 to be observed.
Class
Scale
Information:
Tolerances
All Dimensions
in mm
5:1
1
±0,1
5,08
Masse nur informatorisch,
keine Prüfpläne erstellen.
All rights reserved.
Only for Information.
To ensure that this is the latest
version of this drawing, please
contact one of the ERNI companies
before using.
l
Index
19.07.2013
Date
Designation
Subject to modification without
prior notice.
Drawing will not be updated.
High Current Male Contact
Right Angle Solder Termination
www.ERNI.com
Class
014316
STVSKO
I
A3
