BZT03-Series
Vishay Semiconductors
Zener Diodes with Surge Current Specification
Features
• Glass passivated junction
• Hermetically sealed package
• Clamping time in picoseconds
• Compliant to RoHS directive 2002/95/EC
and in accordance to WEEE 2002/96/EC
• Halogen-free according to IEC 61249-2-21
definition
949539
Applications
• Medium power voltage regulators and medium
power transient suppression circuits
Mechanical Data
Case:
SOD-57
Weight:
approx. 369 mg
Packaging codes/options:
TAP / 5 k ammopack (52 mm tape) / 25 k/box
TR / 5 k 10" reel
Absolute Maximum Ratings
T
amb
= 25 °C, unless otherwise specified
Parameter
Power dissipation
Repetitive peak reverse power
dissipation
Non repetitive peak surge power
dissipation
Junction temperature
Storage temperature range
t
p
= 100
μs,
T
j
= 25 °C
Test condition
l = 10 mm, T
L
= 25 °C
T
amb
= 25 °C
Symbol
P
V
P
V
P
ZRM
P
ZSM
T
j
T
stg
Value
3.25
1.3
10
600
175
- 65 to + 175
Unit
W
W
W
W
°C
°C
Thermal Characteristics
T
amb
= 25 °C, unless otherwise specified
Parameter
Junction ambient
Test condition
l = 10 mm, T
L
= constant
On PC board with spacing 25 mm
Symbol
R
thJA
R
thJA
Value
46
100
Unit
K/W
K/W
Electrical Characteristics
T
amb
= 25 °C, unless otherwise specified
Parameter
Forward voltage
Test condition
I
F
= 0.5 A
Symbol
V
F
Min.
Typ.
Max.
1.2
Unit
V
Document Number 85599
Rev. 1.5, 26-Aug-10
For technical questions within your region, please contact one of the following:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
www.vishay.com
1
BZT03-Series
Vishay Semiconductors
Typical Characteristics
T
amb
= 25 °C, unless otherwise specified
3.0
50
3
I
F
– Forward Current (A )
2.5
2.0
T
j
=25°C
1.5
1.0
0.5
0
25
50
7
2
94 9086a
0
94 9585
0.5
1.0
1.5
2.0
V
F
– Forward
Voltage
(
V
)
Figure 1. Epoxy Glass Hard Tissue, Board Thickness 1.5 mm,
R
thJA
≤
100 K/W
Figure 3. Forward Current vs. Forward Voltage
P
tot
–Total Power Dissipation (
W
)
4
l=10mm
3
15mm
2
20mm
1
see Fig.1
0
0
40
80
P
ZSM
–
Non-Repetitive
Surge Power
Dissipation (W )
l
l
10000
T
j
=25°C
1000
T
L
=constant
100
120
160
200
94 9586
10
0.01
0.1
1
10
100
94 9584
T
amb
– Ambient T
emperature ( °C )
t
p
– Pulse Length ( ms )
Figure 2. Total Power Dissipation vs. Ambient Temperature
Figure 4. Non Repetitive Surge Power Dissipation vs.
Pulse Length
Package Dimensions
in millimeters (inches):
SOD-57
0.82 (0.032) max.
26 (1.024) min.
4 (0.157) max.
26 (1.024) min.
3.6 (0.142) max.
20543
www.vishay.com
4
For technical questions within your region, please contact one of the following: Document Number 85599
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
Rev. 1.5, 26-Aug-10
