Series AM2G-Z
2 Watt | DC-DC Converter
FEATURES:
•
Regulated
•
High Efficiency up to 80%
•
Remote On/Off Control
•
8 Pin SIP Package
•
•
•
•
Operating Temperature -40
o
C to +85
o
C
Continuous Short Circuit Protection
Wide 2:1 Input Range
Input / Output Isolation 1000 & 3000VDC
Models
Single Output
Model
AM2G-0503SZ
AM2G-0505SZ
AM2G-0507SZ
AM2G-0509SZ
AM2G-0512SZ
AM2G-0515SZ
AM2G-0518SZ
AM2G-0524SZ
AM2G-1203SZ
AM2G-1205SZ
AM2G-1207SZ
AM2G-1209SZ
AM2G-1212SZ
AM2G-1215SZ
AM2G-1218SZ
AM2G-1224SZ
AM2G-2403SZ
AM2G-2405SZ
AM2G-2407SZ
AM2G-2409SZ
AM2G-2412SZ
AM2G-2415SZ
AM2G-2418SZ
AM2G-2424SZ
AM2G-4803SZ
AM2G-4805SZ
AM2G-4807SZ
AM2G-4809SZ
AM2G-4812SZ
AM2G-4815SZ
AM2G-4818SZ
AM2G-4824SZ
AM2G-0503SH30Z
AM2G-0505SH30Z
AM2G-0507SH30Z
AM2G-0509SH30Z
AM2G-0512SH30Z
AM2G-0515SH30Z
AM2G-0518SH30Z
AM2G-0524SH30Z
AM2G-1203SH30Z
AM2G-1205SH30Z
AM2G-1207SH30Z
AM2G-1209SH30Z
AM2G-1212SH30Z
Input
Voltage
(V)
4.5-9
4.5-9
4.5-9
4.5-9
4.5-9
4.5-9
4.5-9
4.5-9
9-18
9-18
9-18
9-18
9-18
9-18
9-18
9-18
18-36
18-36
18-36
18-36
18-36
18-36
18-36
18-36
36-72
36-72
36-72
36-72
36-72
36-72
36-72
36-72
4.5-9
4.5-9
4.5-9
4.5-9
4.5-9
4.5-9
4.5-9
4.5-9
9-18
9-18
9-18
9-18
9-18
Output
Voltage (V)
3.3
5
7.2
9
12
15
18
24
3.3
5
7.2
9
12
15
18
24
3.3
5
7.2
9
12
15
18
24
3.3
5
7.2
9
12
15
18
24
3.3
5
7.2
9
12
15
18
24
3.3
5
7.2
9
12
Output
Current Max
(mA)
500
400
278
222
167
133
111
83
500
400
278
222
167
133
111
83
500
400
278
222
167
133
111
83
500
400
278
222
167
133
111
83
500
400
278
222
167
133
111
83
500
400
278
222
167
Isolation
(VDC)
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
Capacitive
Load Max
(μF)
3300
3300
470
470
470
470
220
220
3300
3300
470
470
470
470
220
220
3300
3300
470
470
470
470
220
220
3300
3300
470
470
470
470
220
220
3300
3300
470
470
470
470
220
220
3300
3300
470
470
470
Input Current
Full Load | No
Load (mA)
492
571
560
555
555
547
540
533
205
216
215
213
208
213
210
208
98
108
106
104
104
104
104
104
48
56
55
53
53
53
53
52
492
571
560
555
555
547
540
533
205
216
215
213
208
15
15
15
30
30
30
30
60
15
15
15
15
15
15
15
15
8
8
8
8
8
8
8
8
6
6
6
6
6
6
6
6
15
15
15
30
30
30
30
60
15
15
15
15
15
Efficiency
(%)
67
70
71
72
72
73
70
75
67
77
75
78
80
78
78
80
70
77
74
80
80
80
78
80
71
74
74
78
78
78
78
80
67
70
71
72
72
73
70
75
67
77
75
78
80
www.aimtec.com
F 051e R11.Q
REV: 02/20/A
Tel: +1 514 620 2722
1 of 8
Toll free: + 1 888 9 AIMTEC (924 6832)
North America only
Series AM2G-Z
2 Watt | DC-DC Converter
Models
Single Output (continued)
Model
AM2G-1215SH30Z
AM2G-1218SH30Z
AM2G-1224SH30Z
AM2G-2403SH30Z
AM2G-2405SH30Z
AM2G-2407SH30Z
AM2G-2409SH30Z
AM2G-2412SH30Z
AM2G-2415SH30Z
AM2G-2418SH30Z
AM2G-2424SH30Z
AM2G-4803SH30Z
AM2G-4805SH30Z
AM2G-4807SH30Z
AM2G-4809SH30Z
AM2G-4812SH30Z
AM2G-4815SH30Z
AM2G-4818SH30Z
AM2G-4824SH30Z
Input
Voltage
(V)
9-18
9-18
9-18
18-36
18-36
18-36
18-36
18-36
18-36
18-36
18-36
36-72
36-72
36-72
36-72
36-72
36-72
36-72
36-72
Output
Voltage (V)
15
18
24
3.3
5
7.2
9
12
15
18
24
3.3
5
7.2
9
12
15
18
24
Output
Current Max
(mA)
133
111
83
500
400
278
222
167
133
111
83
500
400
278
222
167
133
111
83
Isolation
(VDC)
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
Capacitive
Load Max
(μF)
470
220
220
3300
3300
470
470
470
470
220
220
3300
3300
470
470
470
470
220
220
Input Current
Full Load | No
Load (mA)
213
210
208
98
108
106
104
104
104
104
104
48
56
55
53
53
53
53
52
15
15
15
8
8
8
8
8
8
8
8
6
6
6
6
6
6
6
6
Efficiency
(%)
78
78
80
70
77
74
80
80
80
78
80
71
74
74
78
78
78
78
80
Models
Dual Output
Model
AM2G-0503DZ
AM2G-0505DZ
AM2G-0507DZ
AM2G-0509DZ
AM2G-0512DZ
AM2G-0515DZ
AM2G-0518DZ
AM2G-0524DZ
AM2G-1203DZ
AM2G-1205DZ
AM2G-1207DZ
AM2G-1209DZ
AM2G-1212DZ
AM2G-1215DZ
AM2G-1218DZ
AM2G-1224DZ
AM2G-2403DZ
AM2G-2405DZ
AM2G-2407DZ
AM2G-2409DZ
AM2G-2412DZ
AM2G-2415DZ
AM2G-2418DZ
AM2G-2424DZ
AM2G-4803DZ
AM2G-4805DZ
AM2G-4807DZ
AM2G-4809DZ
AM2G-4812DZ
Input
Voltage
(V)
4.5-9
4.5-9
4.5-9
4.5-9
4.5-9
4.5-9
4.5-9
4.5-9
9-18
9-18
9-18
9-18
9-18
9-18
9-18
9-18
18-36
18-36
18-36
18-36
18-36
18-36
18-36
18-36
36-72
36-72
36-72
36-72
36-72
Output
Voltage (V)
±3.3
±5
±7.2
±9
±12
±15
±18
±24
±3.3
±5
±7.2
±9
±12
±15
±18
±24
±3.3
±5
±7.2
±9
±12
±15
±18
±24
±3.3
±5
±7.2
±9
±12
Output
Current Max
(mA)
±250
±200
±139
±111
±83
±67
±56
±42
±250
±200
±139
±111
±83
±67
±56
±42
±250
±200
±139
±111
±83
±67
±56
±42
±250
±200
±139
±111
±83
Isolation
(VDC)
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
Capacitive
Load Max
(μF)
±1000
±1000
±220
±220
±220
±220
±100
±100
±1000
±1000
±220
±220
±220
±220
±100
±100
±1000
±1000
±220
±220
±220
±220
±100
±100
±1000
±1000
±220
±220
±220
Input Current
Full Load | No
Load (mA)
471
571
560
540
533
533
540
563
188
222
215
210
208
210
210
219
94
106
106
105
104
104
104
106
47
56
55
53
53
20
20
20
20
25
25
30
60
15
15
15
15
15
15
15
30
8
8
8
8
8
8
8
20
6
6
6
6
6
Efficiency
(%)
65
70
70
74
75
75
73
71
67
75
75
79
80
79
78
76
73
78
75
79
80
80
78
78
73
74
75
79
79
www.aimtec.com
F 051e R11.Q
REV: 02/20/A
Tel: +1 514 620 2722
2 of 8
Toll free: + 1 888 9 AIMTEC (924 6832)
North America only
Series AM2G-Z
2 Watt | DC-DC Converter
Models
Dual Output (continued)
Model
AM2G-4815DZ
AM2G-4818DZ
AM2G-4824DZ
Input
Voltage
(V)
36-72
36-72
36-72
Output
Voltage (V)
±15
±18
±24
Output
Current Max
(mA)
±67
±56
±42
Isolation
(VDC)
1000
1000
1000
Capacitive
Load Max
(μF)
±220
±100
±100
Input Current
Full Load | No
Load (mA)
52
53
55
6
6
12
Efficiency
(%)
80
78
75
4.5-9
±3.3
±250
3000
±1000
471
20
65
AM2G-0503DH30Z
4.5-9
±5
±200
3000
±1000
571
20
70
AM2G-0505DH30Z
AM2G-0507DH30Z
4.5-9
±7.2
±139
3000
±220
560
20
70
4.5-9
±9
±111
3000
±220
540
20
74
AM2G-0509DH30Z
4.5-9
±12
±83
3000
±220
533
25
75
AM2G-0512DH30Z
AM2G-0515DH30Z
4.5-9
±15
±67
3000
±220
533
25
75
4.5-9
±18
±56
3000
±100
540
30
73
AM2G-0518DH30Z
4.5-9
±24
±42
3000
±100
563
60
71
AM2G-0524DH30Z
AM2G-1203DH30Z
9-18
±3.3
±250
3000
±1000
188
15
67
9-18
±5
±200
3000
±1000
222
15
75
AM2G-1205DH30Z
9-18
±7.2
±139
3000
±220
215
15
75
AM2G-1207DH30Z
AM2G-1209DH30Z
9-18
±9
±111
3000
±220
210
15
79
9-18
±12
±83
3000
±220
208
15
80
AM2G-1212DH30Z
9-18
±15
±67
3000
±220
210
15
79
AM2G-1215DH30Z
AM2G-1218DH30Z
9-18
±18
±56
3000
±100
210
15
78
9-18
±24
±42
3000
±100
219
30
76
AM2G-1224DH30Z
18-36
±3.3
±250
3000
±1000
94
8
73
AM2G-2403DH30Z
AM2G-2405DH30Z
18-36
±5
±200
3000
±1000
106
8
78
18-36
±7.2
±139
3000
±220
106
8
75
AM2G-2407DH30Z
18-36
±9
±111
3000
±220
105
8
79
AM2G-2409DH30Z
AM2G-2412DH30Z
18-36
±12
±83
3000
±220
104
8
80
18-36
±15
±67
3000
±220
104
8
80
AM2G-2415DH30Z
18-36
±18
±56
3000
±100
104
8
78
AM2G-2418DH30Z
AM2G-2424DH30Z
18-36
±24
±42
3000
±100
106
20
78
36-72
±3.3
±250
3000
±1000
47
6
73
AM2G-4803DH30Z
36-72
±5
±200
3000
±1000
56
6
74
AM2G-4805DH30Z
AM2G-4807DH30Z
36-72
±7.2
±139
3000
±220
55
6
75
36-72
±9
±111
3000
±220
53
6
79
AM2G-4809DH30Z
36-72
±12
±83
3000
±220
53
6
79
AM2G-4812DH30Z
AM2G-4815DH30Z
36-72
±15
±67
3000
±220
52
6
80
36-72
±18
±56
3000
±100
53
6
78
AM2G-4818DH30Z
36-72
±24
±42
3000
±100
55
12
75
AM2G-4824DH30Z
NOTE: All specifications in this datasheet are measured at an ambient temperature of 25°C, humidity<75%, nominal input voltage and at
rated output load unless otherwise specified.
Input Specifications
Parameters
Voltage range
Filter
Input Reflected Ripple
Current
Absolute Maximum
Rating
Peak Input Voltage time
On/Off Control
5 Vin
12 Vin
24 Vin
48 Vin
Nominal
5
12
24
48
Typical
4.5-9
9-18
18-36
36-72
Capacitor
35
Maximum
Units
VDC
mA p-p
-0.7-12
-0.7-24
-0.7-40
-0.7-80
100
ON – low or open (0Vdc to 0.8Vdc)
OFF – high (4.5Vdc to 15Vdc,
OFF idle current:3.5mA to 15mA Max.)
Tel: +1 514 620 2722
3 of 8
VDC
ms
www.aimtec.com
F 051e R11.Q
REV: 02/20/A
Toll free: + 1 888 9 AIMTEC (924 6832)
North America only
Series AM2G-Z
2 Watt | DC-DC Converter
Isolation Specifications
Parameters
Tested I/O voltage
Resistance
Capacitance
Conditions
60sec
Typical
> 1000
60
Rated
1000 & 3000
Units
VDC
MOhm
pF
Output Specifications
Parameters
Voltage accuracy
Cross Regulation (Dual Output Models)
Short Circuit protection
Short Circuit restart
Line voltage regulation
Load voltage regulation
Temperature coefficient
Ripple & Noise
25% load on output –
100% load 2nd output
±5
Continuous
Auto recovery
LL~HL
load 25~100%, 3.3V Output Models
load 25~100%, Others
±0.02
At 20MHz Bandwidth
80
±0.5
±1.0
±0.5
%
%
%/
o
C
mV p-p
Conditions
Typical
Maximum
±2
Units
%
%
General Specifications
Parameters
Switching frequency
Operating temperature
Storage temperature
Max Case temperature
Cooling
Humidity
Case material
Weight
Dimensions (L x W x H)
MTBF
Conditions
100% load
No derating
Typical
>100
-40 to +85
-40 to +125
Maximum
650
Units
KHz
o
C
o
C
o
C
%
g
+100
Free air convection
95
Non-conductive black plastic (UL94V-0 rated)
4.5
0.86 x 0.36 x 0.44 inch
21.85 x 9.20 x 11.10 mm
>1 610 000 hrs (MIL-HDBK -217F, Ground Benign, t=+25
o
C)
Safety Specifications
Parameters
Agency Approval
CE, UL
EN55032 Class A,
IEC61000-4-2, Perf. Criteria A
IEC61000-4-3, Perf. Criteria A
IEC61000-4-4, Perf. Criteria A (external 220uF/100V cap required)
IEC61000-4-5, Perf. Criteria A (external 220uF/100V cap required)
IEC61000-4-6, Perf. Criteria A
IEC61000-4-8, Perf. Criteria A
IEC/EN/UL 60950-1:2001 & IEC/EN/UL 62368-1
Standards
Switching Frequency vs Input Voltage and Load
www.aimtec.com
F 051e R11.Q
REV: 02/20/A
Tel: +1 514 620 2722
4 of 8
Toll free: + 1 888 9 AIMTEC (924 6832)
North America only
Series AM2G-Z
2 Watt | DC-DC Converter
Pin Out Specification
Pin
1
2
3
5
6
7
8
Dimensions
21.85
(0.86)
1000 & 3000VDC
Single
Dual
- V Input
+ V Input
On/Off Control
N.C.
+ V Output
- V Output
N.C.
- V Input
+ V Input
On/Off Control
N.C.
+ V Output
Common
- V Output
9.20
(0.36)
PRINTED
FACE
10.60
(0.42)
11.10
(0.44)
N.C.: Not Connected
0.50
(0.02)
2.54
(0.10)
17.78
(0.70)
3.00
(0.12)
0.50
(0.02)
1
9.20
(0.38)
2
3
5
6
7
8
3.20
(0.13)
0.50
(0.02)
0.25
(0.01)
Note:
Unit: mm (inch)
Case tolerance: ±0.5 (±0.02)
Pin pitch and length tolerance: ±0.35 (±0.014)
Pin diameter: 0.5±0.05 (0.02±0.002)
Control ON/OFF pin connection example:
1K
MCU
Vcc-5V
PIN 3
1N4148
CONVERTER
The voltage could be applied trough a limiting resistor and a switching diode. The converter is in a low power mode during
high level phase.
Conducted Emissions:
C1
100µF/100V
L1
12 µH
www.aimtec.com
F 051e R11.Q
REV: 02/20/A
Tel: +1 514 620 2722
5 of 8
Toll free: + 1 888 9 AIMTEC (924 6832)
North America only
京公网安备 11010802033920号
EEWORLD
