BZX84C…CAW Series
SILICON PLANAR ZENER DIODES
3
1
2
Absolute Maximum Ratings (T
a
= 25
O
C)
Parameter
Power Dissipation
Operating Junction and Storage Temperature Range
Symbol
P
D
T
j
,T
S
1. Cathode 2. Cathode 3. Anode
Value
200
- 55 to + 150
Unit
mW
O
C
Electrical Characteristics
at T
a
= 25
O
C
(V
F
= 0.9 V Max. at I
F
= 10 mA)
Type
BZX84C2V4CAW
BZX84C2V7CAW
BZX84C3V0CAW
BZX84C3V3CAW
BZX84C3V6CAW
BZX84C3V9CAW
BZX84C4V3CAW
BZX84C4V7CAW
BZX84C5V1CAW
BZX84C5V6CAW
BZX84C6V2CAW
BZX84C6V8CAW
BZX84C7V5CAW
BZX84C8V2CAW
BZX84C9V1CAW
BZX84C10CAW
BZX84C11CAW
BZX84C12CAW
BZX84C13CAW
BZX84C15CAW
BZX84C16CAW
BZX84C18CAW
BZX84C20CAW
BZX84C22CAW
BZX84C24CAW
BZX84C27CAW
BZX84C30CAW
BZX84C33CAW
BZX84C36CAW
BZX84C39CAW
1)
Marking
Code
BE
BF
BH
BJ
BK
BM
BN
BP
BR
BX
BY
BZ
CA
CB
CC
CD
CE
CF
CH
CJ
CK
CM
CN
CP
CR
CX
CY
CZ
DE
DF
Zener Voltage Range
1)
V
Z
Min.(V)
2.2
2.5
2.8
3.1
3.4
3.7
4
4.4
4.8
5.2
5.8
6.4
7
7.7
8.5
9.4
10.4
11.4
12.4
13.8
15.3
16.8
18.8
20.8
22.8
25.1
28
31
34
37
Max.(V)
2.6
2.9
3.2
3.5
3.8
4.1
4.6
5
5.4
6
6.6
7.2
7.9
8.7
9.6
10.6
11.6
12.7
14.1
15.6
17.1
19.1
21.2
23.3
25.6
28.9
32
35
38
41
at l
ZT
mA
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
2
2
2
2
2
Z
ZT
Max.(Ω)
100
100
95
95
90
90
90
80
60
40
10
15
15
15
15
20
20
25
30
30
40
45
55
55
70
80
80
80
90
130
Dynamic Resistance
at l
ZT
mA
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
2
2
2
2
2
Z
ZK
Max.(Ω)
600
600
600
600
600
600
600
600
500
480
400
150
80
80
80
100
150
150
150
170
200
200
225
225
250
250
300
300
325
350
at I
ZK
mA
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0.5
0.5
0.5
0.5
0.5
Reverse Current
I
R
Max.(µA)
50
20
20
5
5
3
3
3
2
1
3
2
1
0.7
0.5
0.2
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
at V
R
V
1
1
1
1
1
1
1
2
2
2
4
4
5
5
6
7
8
8
8
10.5
11.2
12.6
14
15.4
16.8
18.9
21
23.1
25.2
27.3
Tested with pulses tp = 20 ms.
