UNISONIC TECHNOLOGIES CO., LTD
BYC10
Preliminary
DIODE
ULTRAFAST, LOW SWITCHING
LOSS RECTIFIER DIODE
DESCRIPTION
The UTC
BYC10
is a rectifier diode. It provides the designers with
ultra-fast switching and low switching loss in associated MOSFET.
The UTC
BYC10
can be used in applications, such as
half-bridge/full-bridge switched mode power supplies, active power
factor correction and half-bridge lighting ballasts.
FEATURES
* Low Reverse Recovery Current
* Ultra-Fast Switching
* Low Switching Loss In Associated MOSFET
* Low Thermal Resistance
SYMBOL
ORDERING INFORMATION
Pin Assignment
1
2
Tab
K
A
K
A
K
A
A
K
A
Packing
Tube
Tape Reel
Tape Reel
Ordering Number
Package
Lead Free
Halogen Free
BYC10L-6-TA2-T
BYC10G-6-TA2-T
TO-220-2
BYC10L-6-TA3-T
BYC10G-6-TA3-T
TO-220
BYC10L-6-TF3-T
BYC10G-6-TF3-T
TO-220F
Note:
Pin Assignment: A: Anode K: Cathode Tab: Mounting Base
MARKING
www.unisonic.com.tw
Copyright © 2015 Unisonic Technologies Co., Ltd
1 of 3
QW-R601-023.c
BYC10
Preliminary
DIODE
ABSOLUTE MAXIMUM RATINGS
PARAMETER
SYMBOL
RATINGS
UNIT
Peak Repetitive Reverse Voltage
V
RRM
600
V
Crest Working Reverse Voltage
V
RWM
600
V
Continuous Reverse Voltage T
Tab
≤
114°C
V
R
500
V
δ
=0.5; with reapplied V
RRM(max)
;
Average Forward Current
10
A
I
F(AV)
T
Tab
≤78°C
Repetitive Peak Forward
δ
=0.5; with reapplied V
RRM(max)
;
20
A
I
FRM
Current
T
Tab
≤78°C
t = 10ms
I
FSM
65
A
Non-Repetitive Peak
t = 8.3ms
Forward Current.
sinusoidal; T
J
=150°C prior to
71
A
surge with reapplied V
RWM(max)
Operating Junction Temperature
T
J
150
°C
Storage Temperature
T
STG
-40 ~ +150
°C
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
THERMAL DATA
SYMBOL
θ
JA
θ
JB
RATINGS
60
2
5
UNIT
K/W
K/W
K/W
PARAMETER
Junction to Ambient
TO-220/TO-220-2
Junction to Tab
TO-220F
ELECTRICAL CHARACTERISTICS
(T
J
=25°C, unless otherwise specified)
PARAMETER
SYMBOL
V
F
I
R
t
RR
I
RRM
V
FR
TEST CONDITIONS
I
F
=10A, T
J
=150°C
I
F
=20A, T
J
=150°C
I
F
=10A
V
R
=600V
V
R
=500V, T
J
=100°C
I
F
=1A, V
R
=30V, dI
F
/dt=50A/μs
MIN TYP MAX UNIT
1.4 1.8
V
1.7 2.3
V
2.0 2.9
V
9
200 µA
1.1 3.0 mA
35
55
ns
19
ns
I
F
=10A, V
R
=400V, dI
F
/dt=500A/μs
T
J
=100°C
32
40
ns
3
7.5
A
I
F
=10A,V
R
=400V, dI
F
/dt=100A/μs, T
J
=125°C
I
F
=10A,V
R
=400V, dI
F
/dt=500A/μs, T
J
=125°C
9.5
12
A
I
F
=10A, dI
F
/dt=100A/μs
8
11
V
Forward Voltage
Reverse Current
Reverse Recovery Time
Peak Reverse Recovery Current
Forward Recovery Voltage
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
2 of 3
QW-R601-023.c
BYC10
V
IN
150uH typ
I
L
Preliminary
DIODE
TYPICAL CHARACTERISTICS
V
IN
V
IN
=400V d.c.
Output Diode
500V MOSFET
I
D
I
R
I
F
Inductive load
I
L
V
O
=400V d.c.
Fig.1. Typical application, output rectifier in boost
converter power factor correction circuit. Continuous
conduction mode, where the transistor turns on
whilst forward current is still flowing in the diode.
Fig.2. Typical application, freewheeling diode in half
bridge converter. Continuous conduction mode, where
each transistor turns on whilst forward current is still
flowing in the other bridge leg diode.
UTC assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or
other parameters) listed in products specifications of any and all UTC products described or contained
herein. UTC products are not designed for use in life support appliances, devices or systems where
malfunction of these products can be reasonably expected to result in personal injury. Reproduction in
whole or in part is prohibited without the prior written consent of the copyright owner. The information
presented in this document does not form part of any quotation or contract, is believed to be accurate
and reliable and may be changed without notice.
