TS9013
500mA Low Quiescent Current CMOS LDO
SOT-89
Pin Definition:
1. Ground
2. Input
3. Output
SOT-223
Pin Definition:
1. Input
2. Ground
3. Output
General Description
TS9013 is a positive voltage regulator developed utilizing CMOS technology featured very low power
consumption, low dropout voltage and high output voltage accuracy. Built in low on-resistor provides low dropout
voltage and large output current. A 2.2uF or greater can be used as an output capacitor.
TS9013 are prevented device failure under the worst operation condition with both thermal shutdown and current
fold-back. These series are recommended for configuring portable devices and large current application,
respectively.
Features
●
●
●
●
●
Output current up to 500mA
Low power consumption, 15uA(typ) @Vo=5V
Output voltage
±2%
Internal current limit
Thermal shutdown protection
Ordering Information
Part No.
Package
Packing
TS9013xCW RP
SOT-223
2.5Kpcs / 13” Reel
TS9013xCW RPG
SOT-223
2.5Kpcs / 13” Reel
TS9013xCY RM
SOT-89
1Kpcs / 7” Reel
TS9013xCY RMG
SOT-89
1Kpcs / 7” Reel
Note: Refer to detail ordering information table.
Applications
●
●
●
●
●
Palmtops
Video recorders
Battery powered equipment
PC peripherals
CD-ROM, DVD ROM
Digital signal camera
Typical Application Circuit
●
Absolute Maximum Rating
Parameter
Input Supply Voltage
Recommend Operating Input Voltage
Output Current
Power Dissipation (without heat sink)
Operating Junction Temperature Range
Storage Temperature Range
Lead Soldering Temperature (260 C)
o
Symbol
V
IN
V
IN
Io
SOT-89
SOT-223
P
D
Tj
T
STG
Limit
12
10
500
0.5
0.7
-40 ~ +150
-65 ~ +150
5
Unit
V
V
mA
W
o
o
C
C
S
Notes:
Stress above the listed absolute rating may cause permanent damage to the device.
1/5
Version: G13
TS9013
500mA Low Quiescent Current CMOS LDO
Electrical Characteristics
(Ta = 25
o
C unless otherwise noted)
Parameter
Conditions
TS90135
V
IN
=Vo + 1V,
Io =1mA,
Output Voltage
V
IN
=Vo + 1V,
Io =1mA ~ 500mA
Maximum Output Current
Input Stability
V
IN
=Vo+1V,
V
O
+1V
≤
Vin
≤
V
O
+2V, Io=1mA
V
IN
=Vo+1V,
Load Regulation (Note1)
1mA
≤
IL
≤
500mA
V
IN
=Vo+1V,
1mA
≤
IL
≤
500mA
Io=300mA
Dropout Voltage (Note 2)
Io=500mA
Io=500mA
Quiescent Current
Output Current Limit
Power Supply Rejection
Ratio
Output Voltage Temperature
V
IN
=Vo+1V, Io=0A
V
OUT
< 0.4V
At f=100KHz, Io=10mA
TS90135
TS9013S
TS9013K
TS9013D
TS90135
TS9013S
TS90135
TS9013S
TS9013K
TS9013D
TS9013S
TS9013K
TS9013D
TS90135
TS9013S
TS9013K
TS9013D
Min
4.90
3.23
2.45
1.76
4.85
3.20
2.42
1.74
500
--
--
--
--
--
--
--
550
--
--
Typ
5.0
3.3
2.5
1.8
5.0
3.3
2.5
1.8
--
0.2
40
40
300
500
600
15
--
30
100
Max
5.10
3.36
2.55
1.83
5.10
3.36
2.55
1.83
--
0.3
80
Unit
V
V
mA
%
mV
90
500
600
850
25
--
--
--
uA
mA
dB
ppm/ C
o
mV
Coefficient (Note 3)
Note 1:
Regulation is measured at constant junction temperature, using pulsed ON time.
Note 2:
Dropout is measured at constant junction temperature, using pulsed ON time, and the criterion is V
OUT
inside target value +/-3%.
Ordering information
Voltage
1.8V
2.5V
3.3V
5V
SOT-223
TS9013DCW RP
TS9013DCW RPG
TS9013KCW RP
TS9013KCW RPG
TS9013SCW RP
TS9013SCW RPG
TS90135CW RP
TS90135CW RPG
SOT-89
TS9013DCY RM
TS9013DCY RMG
TS9013KCY RM
TS9013KCY RMG
TS9013SCY RM
TS9013SCY RMG
Packing code information
RP: 2.5kpcs / 13"Reel
RPG: 2.5kpcs / 13"Reel
“G” denotes for Halogen Free
Packing
RM: 1kpcs / 7" Reel
RMG: 1kpcs / 7" Reel
2/5
Version: G13
TS9013
500mA Low Quiescent Current CMOS LDO
SOT-89 Mechanical Drawing
DIM
A
B
C
D
E
F
G
H
I
J
SOT-89 DIMENSION
MILLIMETERS
INCHES
MIN
MAX
MIN
MAX
4.40
4.60
0.173
0.181
1.40
1.75
0.055
0.069
2.40
2.60
0.094
0.102
0.36
0.48
0.014
0.018
1.40
1.60
0.054
0.063
2.90
3.10
0.114
0.122
0.89
1.20
0.035
0.047
--
4.25
--
0.167
1.40
1.60
0.055
0.068
0.38
0.43
0.014
0.017
Marking Diagram
Y
M
= Year Code
= Month Code
(A=Jan,
B=Feb, C=Mar, D=Apl, E=May, F=Jun, G=Jul, H=Aug,
I=Sep, J=Oct, K=Nov, L=Dec)
= Month Code for Halogen Free Product
(O=Jan,
P=Feb, Q=Mar, R=Apl, S=May, T=Jun, U=Jul, V=Aug,
W=Sep, X=Oct, Y=Nov, Z=Dec)
= Lot Code
= Fixed Output Voltage Code
18=1.8V, 25=2.5V, 33=3.3V, 50=5.0V.
L
X
3/5
Version: G13
TS9013
500mA Low Quiescent Current CMOS LDO
SOT-223 Mechanical Drawing
DIM
A
B
C
D
E
F
G
H
I
J
K
SOT-223 DIMENSION
MILLIMETERS
INCHES
MIN
MAX
MIN
MAX
6.350
6.850
0.250
0.270
2.900
3.100
0.114
0.122
3.450
3.750
0.136
0.148
0.595
0.635
0.023
0.025
4.550
4.650
0.179
0.183
2.250
2.350
0.088
0.093
0.835
1.035
0.032
0.041
6.700
7.300
0.263
0.287
0.250
0.355
0.010
0.014
10°
16°
10°
16°
1.550
1.800
0.061
0.071
Marking Diagram
Y
M
= Year Code
= Month Code
(A=Jan,
B=Feb, C=Mar, D=Apl, E=May, F=Jun, G=Jul, H=Aug,
I=Sep, J=Oct, K=Nov, L=Dec)
= Month Code for Halogen Free Product
(O=Jan,
P=Feb, Q=Mar, R=Apl, S=May, T=Jun, U=Jul, V=Aug,
W=Sep, X=Oct, Y=Nov, Z=Dec)
= Lot Code
= Fixed Output Voltage Code
18=1.8V, 25=2.5V, 33=3.3V, 50=5.0V.
L
X
4/5
Version: G13
TS9013
500mA Low Quiescent Current CMOS LDO
Notice
Specifications of the products displayed herein are subject to change without notice. TSC or anyone on its behalf,
assumes no responsibility or liability for any errors or inaccuracies.
Information contained herein is intended to provide a product description only. No license, express or implied, to
any intellectual property rights is granted by this document. Except as provided in TSC’s terms and conditions of
sale for such products, TSC assumes no liability whatsoever, and disclaims any express or implied warranty,
relating to sale and/or use of TSC products including liability or warranties relating to fitness for a particular purpose,
merchantability, or infringement of any patent, copyright, or other intellectual property right.
The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications.
Customers using or selling these products for use in such applications do so at their own risk and agree to fully
indemnify TSC for any damages resulting from such improper use or sale.
5/5
Version: G13
