ES3A-ES3J
3.0A Surface Mount Super-Fast Rectifier
Features
·
Plastic package has underwrites laboratory flammability
Classification 94V-0
·
Glass passivated chip junction
·
Built-in strain relief,
·
Fast switching speed for high efficiency
·
High temperature soldering guaranteed:
260 C/10 seconds
A
B
SMC
Dim
A
B
C
D
E
G
H
J
Min
5.59
6.60
2.75
0.15
7.75
0.10
0.76
2.00
Max
6.22
7.11
3.18
0.31
8.13
0.20
1.52
2.62
C
Mechanical Data
·
Case: JEDED DO-214AB transfer molded plastic
·
Terminals: Solder plated, solderable per
·
MIL-STD-750, method 2026
·
Polarity: Color band denotes cathode end
·
Weight: 0.007 ounce, 0.25 gram
J
D
H
G
E
All Dimensions in mm
Maximum Ratings
•
•
@ T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load derate current by 20%.
SYMBOLS
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
I
R
t
rr
C
J
R
θJA
R
θJL
T
J
T
STG
45
55
17
(-55 to +150)
(-55 to +150)
0.95
ES3A
50
35
50
ES3B
100
70
100
ES3C
150
105
150
ES3D
200
140
200
3.0
100
1.25
5.0
300
35
30
1.7
ES3E
300
210
300
ES3G
400
280
400
ES3J
600
420
600
UNIT
Volts
Volts
Volts
Amps
Amps
Volts
A
nS
pF
/W
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
at T
L
=100
Peak Forward Surge Current
8.3ms single half sine-wave superimposed on
rated load (JEDEC method)
Maximum Instantaneous Forward Voltage @ 3.0A
Maximum DC Reverse Current at rated T
A
= 25
DC Blocking Voltage per element
T
A
= 125
Typical Reverse Recovery Time
Test conditions I
F
=0.5A, I
R
=1.0A, I
RR
=0.25A
Typical Junction Capacitance
(Measured at 1.0MHz and applied reverse voltage of 4.0V)
Typical Thermal Resistance (Note 1)
Operating Junction Temperature Range
Storage Temperature Range
Notes:
1. Thermal resistance from Junction to ambient and from junction to lead mounted on P.C.B. with
0.3”×0.3”(8.0mm
×
8.0mm) copper pad areas.
1of2
FIG.1-TYPICAL FORWARD CURRENT
DERATING CURVE
AVERAGE FORWARD CURRENT,
3.0
FIG.2-MAXIMUM NON-REPETITIVE PEAK
FORWARD SURGE CURRENT
PEAK FORWARD SURGE
150
8.3ms Single Half Sine-Wave
2.0
CURRENT, (A)
(JEDEC Method) T
j
= T
jmax
(A)
100
Single Phase Half Wave
1.0
60Hz Inductive or Resistive Load
0.375″(9.5mm) Lead Length
50
0
0
25
50
75
100
125
150
175
0
1
1 Cycle
2
4
6
8 10
20
40
60
100
AMBIENT TEMPERATURE, ( C)
FIG.3-TYPICAL INSTANTANEOUS
FORWARD CHARACTERISTICS
10
NUMBER OF CYCLES AT 60 Hz
FIG.4-TYPICAL REVERSE
CHARACTERISTICS
INSTANTANEOUS REVERSE CURRENT,
10
INSTANTANEOUS FORWARD CURRENT,
3D
ES
3E
1.0
°
ES
3J
ES
3A-
-3
G
1.0
0.1
T
J
=25 C
Pulse Width=300us
1% Duty Cycle
(μA)
(A)
T
J
=125 C
0.1
0.01
T
J
=25
°
0.001
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
0.01
0
20
40
60
80
°
100
120
140
INSTANTANEOUS FORWARD VOLTAGE,(V)
FIG.5-TYPICAL JUNCTION CAPACITANCE
1000
PERCENT OF RATED PEAK
REVERSE VOLTAGE,(%)
℃
JUNCTION CAPACITANCE,(pF)
F1G.6-TEST CIRCUIT DIAGRAM AND
REVERSE RECOVERY TIME CHARACTERISTIC
TRR
50Ω
10Ω
NONINDUCTIVE NONINDUCTIVE
(-)
100
(+)
25 Vdc
(approx.)
(-)
T
J
=25 C
f=1MHz
Vsig=50mVp-p
ES3A-ES3D
ES3E-ES3J
D.U.T.
PULSE
GENERATIOR
(NOTE 2)
(+)
OSCILLOSCOPE
(NOTE 1)
+0.5A
0
-0.25A
1Ω
NON
INDUCTIVE
-1.0A
1cm
NOTES : 1.Rise Time=7ns max. Input Impedance=
SET TIME BASE FOR
°
10
0.1
1.0
10
100
REVERSE VOLTAGE,(V)
1 megohm. 22pF
2.Rise time=10ns max. Source Impedance=
50 ohms
50/100ns/cm
2of2
