Rev A
PSSBU58 Series
2 Pin Input Connector
60 Watt, Single Output
AC/DC Open Frame Power Supply
FEATURES
●
Single Output
●
RoHS Compliant
●
Class I Insulation
●
Internal EMI Filter
●
2-Pin Input Connector
●
Output Voltage Available from 5VDC to 48VDC
●
Wide Input Voltage Range: 90~264VAC, 47~63Hz
●
Input Surge Current, Over Voltage, and Over Load Protection
DESCRIPTION
The PSSBU58 series of AC/DC switching mode power supplies provides 60 Watts of continuous output power in an open frame
constructed design. This series has single output supplies with a universal input range of 90~264VAC. These units are ideally suited
for use in portable equipment as well as many other applications. All models meet CISPR-22 class B emission limits and comply
with new CE requirements. All models are input surge current, output voltage, and over load protected. All units are also 100%
burn-in tested.
SPECIFICATIONS:
PSSBU58 Series
All specifications are based on 25°C, Nominal Input Voltage, and Maximum Output Current unless otherwise noted.
We reserve the right to change specifications based on technological advances.
SPECIFICATION
INPUT (V
in
)
Operating Voltage Range
Input Frequency
Input Current (Low Line)
Input Current (High Line)
Inrush Current (Low Line)
Inrush Current (High Line)
Safety Ground Leakage Current
Start-Up Time
OUTPUT (V
o
)
Output Voltage Range
Load Regulation
Line Regulation
Output Power
Output Current Range
Ripple & Noise (peak to peak)
Transient Response Time
Hold-Up Time
PROTECTION
Over Voltage Protection
Over Current Protection
GENERAL
Efficiency
Dielectric Withstanding Voltage
For Primary to Secondary
Dielectric Withstanding Voltage
For Primary to Ground
Isolation Resistance
No Load Power Consumption
ENVIRONMENTAL
Operating Temperature
Storage Temperature
Relative Humidity
Temperature Coefficient
MTBF
PHYSICAL
Weight
Dimensions
SAFETY
EMI Requirements for CISPR-22
EMI Requirements for FCC PART-15
TEST CONDITIONS
Min
90
47
Nom
Max
264
63
1.2
0.6
15
30
0.75
2
Unit
VAC
Hz
A
A
A
A
mA
s
%
%
W
%
ms
ms
%
%
%
VDC
VDC
Io = Full Load, Vin = 115VAC
Io = Full Load, Vin = 230VAC
Io = Full Load, 25°C, Cool Start, Vin = 115VAC
Io = Full Load, 25°C, Cool Start, Vin = 230VAC
Io = Full Load, Vin = 240VAC
Io = Full Load, Vin = 100VAC
Vin = 230VAC
Io = Full Load
Vin = 90 to 264VAC
Full Load, Vin = 90VAC
Io = Full Load to Half Load, Vin = 100VAC
Io = Full Load, Vin = 110VAC
0.3
12
26
0.4
1
0
See Rating Chart
3
5
0.5
1
60
See Rating Chart
0.5
1
4
132
150
90
12
112
110
Io = Full Load, Vin = 230VAC
Primary to Secondary
Primary to Ground
Test Voltage = 500VDC
No Load, Vin = 240VAC
Derate linearly from 100% Load at 40°C to 50% load at 70°C
All Outputs
Operating temperature at 25°C, calculated per MIL-HDBK-217F
80
4242
2121
50
0.1
0
-40
5
-0.04
0.5
+70
+85
95
+0.04
100,000 hours
MΩ
W
°C
°C
%
%/°C
Approximately 140 grams
4.00(L) x 2.00(W) x 1.00(H) inches
101.6(L) x 50.8(W) x 25.4(H) mm
Vin = 220VAC
Vin = 110VAC
B
B
Class
Class
Wall Industries, Inc. 5 Watson Brook Road Exeter, NH 03833
603-778-2300 www.wallindustries.com Fax 603-778-9797
Rev A
PSSBU58 Series
2 Pin Input Connector
60 Watt, Single Output
AC/DC Open Frame Power Supply
MODEL SELECTION TABLE
Model Number
PSSBU58-102
PSSBU58-103
PSSBU58-104
PSSBU58-105
PSSBU58-106
PSSBU58-107
PSSBU58-108
PSSBU58-109
PSSBU58-110
PSSBU58-111
Preset Voltage
6 VDC
8 VDC
11 VDC
13 VDC
16 VDC
21 VDC
27 VDC
33 VDC
40 VDC
48 VDC
Output
Voltage Range
5 ~ 6 VDC
6 ~ 8 VDC
8 ~ 11 VDC
11 ~ 13 VDC
13 ~ 16 VDC
16 ~ 21 VDC
21 ~ 27 VDC
27 ~ 33 VDC
33 ~ 40 VDC
40 ~ 48 VDC
Output
Current Range
8.00 ~ 6.66A
8.00 ~ 6.00A
6.87 ~ 5.00A
5.45 ~ 4.61A
4.23 ~ 3.43A
3.75 ~ 2.85A
2.85 ~ 2.22A
2.22 ~ 1.81A
1.81 ~ 1.50A
1.50 ~ 1.20A
Total Regulation
5%
5%
5%
5%
5%
5%
3%
3%
3%
2%
Max Output Power
40W
48W
55W
60W
60W
60W
60W
60W
60W
60W
NOTES
1. The output voltage is specified as a range (Ex: 40 ~ 48VDC); the preset voltage will be set as standard models if nothing
different is requested. Please contact factory for ordering details.
2. Input connector mates with Molex housing 35977-0300 and Molex 35922 series crimp terminal.
MECHANICAL DRAWING
Unit: inches (mm)
Input Connector mates with Molex housing 35977-0300 and
Molex 35922 series crimp terminal.
PIN CONNECTIONS
Pin
1
2
3
4
5
6
Single Output
OUT
OUT
OUT
RTN
RTN
RTN
P/N: PSSBU58-XXX-H3 or PSSBU-XXX-H4
MECHANICAL OPTIONS
Options
Mounting Holes
A
B
C
D
H3
0.13 (3.2±0.5)
0.12 (3.15±0.5)
0.12 (3.15±0.5)
H4
0.16 (4.0±0.5)
0.17 (4.3±0.5)
0.17 (4.3±0.5)
3.75 (95.3±0.5) 3.66 (93.0±0.5)
1.75 (44.5±0.5) 1.69 (42.8±0.5)
Wall Industries, Inc. 5 Watson Brook Road Exeter, NH 03833
603-778-2300 www.wallindustries.com Fax 603-778-9797
