NRE-JL221M100V12.5X25F

Description
CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 63 V, 100 uF, THROUGH HOLE MOUNT
CategoryPassive components
File Size80KB,3 Pages
ManufacturerNIC
Websitehttps://www.niccomp.com
Download Datasheet Parametric View All

NRE-JL221M100V12.5X25F Overview

CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 63 V, 100 uF, THROUGH HOLE MOUNT

NRE-JL221M100V12.5X25F Parametric

Parameter NameAttribute value
Maximum operating temperature105 Cel
Minimum operating temperature-40 Cel
negative deviation20 %
positive deviation20 %
Rated DC voltage urdc63 V
Processing package descriptionRADIAL LEADED, ROHS COMPLIANT
stateACTIVE
Installation featuresTHROUGH HOLE MOUNT
Manufacturer SeriesNRE-JL
capacitance100 uF
packaging shapeCYLINDRICAL PACKAGE
Capacitor typeNON SOLID
Terminal shapeWIRE
polarityPOLARIZED
tangent angle0.09
ripple current304.5mA
leakage current63uA
Miniature Aluminum Electrolytic Capacitors
ULTRA LOW IMPEDANCE, RADIAL LEADS, POLARIZED, ALUMINUM ELECTROLYTIC
FEATURES
• VERY LOW IMPEDANCE & HIGH RIPPLE CURRENT
• LONG LIFE AT 105°C (4000 ~ 10,000 hrs.)
• HIGH STABILITY AT LOW TEMPERATURE
• IDEALLY FOR SWITCHING POWER SUPPLIES & CONVERTORS
CHARACTERISTICS
Rated Voltage Range
Capacitance Range
Operating Temperature Range
Capacitance Tolerance
Maximum Leakage Current
After 2 Minutes at 20°C
6.3 ~ 100Vdc
1.0 ~ 15,000μF
-40°C ~ +105°C
±20% (M)
0.01CV or 3μA
whichever is greater
W.V. (Vdc)
S.V. (Vdc)
C < 1,000μF
C = 2,200μF
C = 3,300μF
C = 4,700μF
C = 6,800μF
C = 10,000μF
C = 15,000μF
Z-25°C/Z+20°C
Z-40°C/Z+20°C
Case Diameter
φ5mm
φ6.3mm
&
φ8mm
φ10mm
~
φ16mm
Capacitance Change
Tan
δ
Leakage Current
Shelf Life Test
105°C 1,000 Hours
No Load
Capacitance Change
Tan
δ
Leakage Current
NRE-JL Series
Max. Tan
δ
at 120Hz/20°C
Low Temperature Stability
Impedance Ratio @ 120Hz
6.3
8
0.22
0.24
0.26
0.28
0.32
0.40
0.50
4
8
10
13
0.19
0.21
0.23
0.25
0.29
0.37
-
3
6
16
20
0.16
0.18
0.20
0.22
0.26
-
-
2
4
25
35
32
44
0.14
0.12
0.16
0.14
0.18
0.16
0.20
-
-
-
-
-
-
-
2
2
3
3
Life Hours
50
63
0.10
0.12
-
-
-
-
-
2
3
63
79
0.09
-
-
-
-
-
-
2
3
100
125
0.08
-
-
-
-
-
-
2
3
Load Life Hours
Load Life Test at Rated W.V. & 105°C
6.3V to 10V
4,000
6,000
8,000
16V to 100V
5,000
7,000
10,000
Within ±25% (6.3V ±30%) of initial measured value
Less than 200% of specified value
Less than specified value
Within ±25% of initial measured value
Less than 200% of specified value
Less than specified value
PART NUMBER SYSTEM
NRE-JL 102 M 25V 10X20 TB F
RoHS Compliant
TB = Tape & Box*
Case Size (mm)
Working Voltage
Tolerance Code M=20%
Capacitance Code in
μF
Series
*see tape specification for details
Please review the notes on correct use, safety and precautions found on
pages T10
&
T11
of NIC’s
Electrolytic Capacitor catalog.
Also found at
www.niccomp.com/precautions
If in doubt or uncertainty, please review your specific application - process
details with NIC’s technical support personnel:
tpmg@niccomp.com
PRECAUTIONS
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
SPECIFICATIONS ARE SUBJECT TO CHANGE
