Continental Device India Limited
An ISO/TS 16949, ISO 9001 and ISO 14001 Certified Company
NPN POWER TRANSISTOR
2N3055HV
TO-3
Metal Can Package
Switching Regulator and Power Amplifier Applications
ABSOLUTE MAXIMUM RATINGS
DESCRIPTION
Collector Base Voltage ( Open Emitter)
Collector Emitter Voltage (Open Base)
Emitter Base Voltage
Collector Current
Base Current
Total Power Dissipation up toT
c
=25ºC
Junction Temperature
Storage Temperature
THERMAL RESISTANCE
Junction to Case
R
th(j-c)
1.75
ºC/W
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
I
B
P
tot
T
j
T
stg
VALUE
100
100
7.0
15
7.0
100
200
- 65 to +200
UNITS
V
V
V
A
A
W
ºC
ºC
ELECTRICAL CHARACTERISTICS (T
C
=25ºC unless specified otherwise)
DESCRIPTION
Breakdown Voltages
V
CEO(sus)
*
V
CBO
V
EBO
I
CEX
I
CEX
Collector Cut off Current
Emitter Cut off Current
Collector Emitter Saturation Voltage
Base Emitter on Voltage
DC Current Gain
I
CEO
I
EBO
V
CE(Sat)
*
V
BE(on)
*
h
FE
*
h
FE
*
I
C
=200mA, I
B
=0
I
C
=1mA, I
E
= 0
I
E
=1mA, I
C
=0
V
CE
=100V, V
BE
=(off)=1.5V
T
c
=150ºC
V
CE
=100V, V
BE
=(off)=1.5V
V
CE
=30V, I
B
=0
V
BE
=7V, I
C
=0
I
C
=4A, I
B
=400mA
I
C
=10A, I
B
=3.3A
I
C
=4A, V
CE
=4V
I
C
=4A, V
CE
=4V
I
C
=10A, V
CE
=4V
100
100
7
1.0
V
V
V
mA
SYMBOL
TEST CONDITION
MIN
MAX
UNITS
Collector Cut off Current
20
5
5.0
0.7
5.0
1.1
3.0
2
100
mA
mA
V
V
Continental Device India Limited
Data Sheet
Page 1 of 4
NPN POWER TRANSISTOR
2N3055HV
TO-3
Metal Can Package
ELECTRICAL CHARACTERISTICS (T
C
=25ºC unless specified otherwise)
DESCRIPTION
Second Breakdown Collector Current
with Base Forward Biased
Dynamic Characteristics
Transition Frequency
*Pulse Test: <300µs, Duty Cycle =2%
µ
SYMBOL
I
S
/b
TEST CONDITION
V
CE
=35V,t=1.0 sec,
Nonrepetitive
MIN
2.87
MAX
UNITS
A
f
T
I
C
=0.5A, V
CE
=10V, f=1MHz
2.5
MHz
