LR1108G-18-AA3-A-R datasheet, PDF

Datasheet> All Categories > Power/power management> The power supply circuit> LR1108G-18-AA3-A-R

LR1108G-18-AA3-A-R: DescriptionFixed Positive LDO Regulator, 1.8V, CMOS, PDSO3, SOT-223, 3 PIN; CategoryPower/power management The power supply circuit; File Size290KB，10 Pages; ManufacturerUNISONIC TECHNOLOGIES CO.,LTD; Websitehttp://www.unisonic.com.tw/; Environmental Compliance

Download Datasheet Parametric Compare View All

LR1108G-18-AA3-A-R Overview

Fixed Positive LDO Regulator, 1.8V, CMOS, PDSO3, SOT-223, 3 PIN

LR1108G-18-AA3-A-R Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	1154063604
package instruction	SOP, SOT-223
Reach Compliance Code	compliant
ECCN code	EAR99
Adjustability	FIXED
Nominal dropback voltage 1	0.3 V
Maximum absolute input voltage	7 V
Maximum input voltage	7 V
Minimum input voltage	2.5 V
JESD-30 code	R-PDSO-G3
Number of functions	1
Output times	1
Number of terminals	3
Working temperatureTJ-Max	85 °C
Working temperature TJ-Min	-40 °C
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Maximum output current 1	1 A
Maximum output voltage 1	1.854 V
Minimum output voltage 1	1.746 V
Nominal output voltage 1	1.8 V
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	SOT-223
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
method of packing	TR
Certification status	Not Qualified
Regulator type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
surface mount	YES
technology	CMOS
Terminal form	GULL WING
Terminal location	DUAL
Maximum voltage tolerance	3%

Preview

Download Datasheet

View All

UNISONIC TECHNOLOGIES CO., LTD

LR1108/E/N

1A FAST ULTRA LOW

DROPOUT LINEAR

REGULATOR



DESCRIPTION

SOT-223

CMOS IC

TO-252

The UTC

LR1108/E/N

is an ultra low-dropout linear

regulators. Wide output voltage range options are available. The

fast response characteristic to make UTC

LR1108/E/N

suitable

for low voltage microprocessor application. The low quiescent

current operation and low dropout quality caused by the CMOS

process.

The UTC

LR1108/E/N

has ultra low dropout voltage

300mV at 1A load current typically.

The ground pin current is typically 150uA at 1mA load current.

ERROR Flag: When the output voltage drops 10% below

nominal value Error flag goes low.

SET/ADJ Mode (for

LR1108):

Connect an external resistive

voltage-divider from V

OUT

to this pin to set the output voltage from

1.145V to 5V.

Output Voltage Precision: Multiple output voltage options are

available and ranging from 1.2V ~ 5.0V at room temperature with

a guaranteed accuracy of ±1.5%, and ±3.0% when varying line,

load and temperature.

1 2

SOT-23

(EIAJ SC-59)

SOT-23-5

(JEDEC TO-236)

1 2

SOT-25

SOT-89

DFN3030-8



FEATURES

* ERROR Flag Indicates Output Status

* Sense option improves better load regulation

* Low Output Capacitor Required

* Over temperature Protection And Over current

Protection

* Ultra Low Dropout Voltage

* Low Ground Pin Current

* 0.65% Load Regulation

* The Guaranteed Output Current is 1A DC

* Output Voltage Accuracy ± 1.5%

www.unisonic.com.tw

1 of 10

QW-R102-031.Z

LR1108G-18-AA3-A-R Related Products

	LR1108G-18-AA3-A-R	LR1108G-18-AB3-D-R	LR1108G-33-AA3-A-R	LR1108G-33-AA3-D-R	LR1108L-33-AA3-A-R	LR1108L-33-AA3-D-R
Description	Fixed Positive LDO Regulator, 1.8V, CMOS, PDSO3, SOT-223, 3 PIN	Fixed Positive LDO Regulator, 1.8V, CMOS, PSSO3, SOT-89, 3 PIN	Fixed Positive LDO Regulator, 3.3V, 0.5V Dropout, CMOS, PDSO3, SOT-223, 3 PIN	Fixed Positive LDO Regulator, 3.3V, 0.5V Dropout, CMOS, PDSO3, SOT-223, 3 PIN	Fixed Positive LDO Regulator, 3.3V, 0.5V Dropout, CMOS, PDSO3, SOT-223, 3 PIN	Fixed Positive LDO Regulator, 3.3V, 0.5V Dropout, CMOS, PDSO3, SOT-223, 3 PIN
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to
Objectid	1154063604	1154063607	1154063625	1154063627	1154063672	1154063674
package instruction	SOP, SOT-223	, TO-243	SOP, SOT-223	SOP, SOT-223	SOP, SOT-223	SOP, SOT-223
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Adjustability	FIXED	FIXED	FIXED	FIXED	FIXED	FIXED
Nominal dropback voltage 1	0.3 V	0.3 V	0.3 V	0.3 V	0.3 V	0.3 V
Maximum absolute input voltage	7 V	7 V	7 V	7 V	7 V	7 V
Maximum input voltage	7 V	7 V	7 V	7 V	7 V	7 V
Minimum input voltage	2.5 V	2.5 V	4.3 V	4.3 V	4.3 V	4.3 V
JESD-30 code	R-PDSO-G3	R-PSSO-F3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3
Number of functions	1	1	1	1	1	1
Output times	1	1	1	1	1	1
Number of terminals	3	3	3	3	3	3
Working temperatureTJ-Max	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C
Working temperature TJ-Min	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
Maximum output current 1	1 A	1 A	1 A	1 A	1 A	1 A
Maximum output voltage 1	1.854 V	1.854 V	3.399 V	3.399 V	3.399 V	3.399 V
Minimum output voltage 1	1.746 V	1.746 V	3.201 V	3.201 V	3.201 V	3.201 V
Nominal output voltage 1	1.8 V	1.8 V	3.3 V	3.3 V	3.3 V	3.3 V
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Encapsulate equivalent code	SOT-223	TO-243	SOT-223	SOT-223	SOT-223	SOT-223
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE
method of packing	TR	TAPE AND REEL	TR	TR	TR	TR
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Regulator type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
surface mount	YES	YES	YES	YES	YES	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Terminal form	GULL WING	FLAT	GULL WING	GULL WING	GULL WING	GULL WING
Terminal location	DUAL	SINGLE	DUAL	DUAL	DUAL	DUAL
Maximum voltage tolerance	3%	3%	3%	3%	3%	3%
encapsulated code	SOP	-	SOP	SOP	SOP	SOP
Maximum drop-back voltage 1	-	-	0.5 V	0.5 V	0.5 V	0.5 V
